Turn-on angle vs. Iout
0
50
100
150
200
250
300
5 25 45 65 85 105 125 145 165
Turn-on angle (degrees)
Iout (mA)
www.ti.com
Performance Data and Typical Characteristic Curves
7.6 Switch Node Voltage Valley Switching
Figure 9. Switch Node Waveform
(Ch1 - LED current Ch2- switch node Ch3 - rectified line voltage)
7.7 Triac Dimmer LED Current vs Conduction Angle
Figure 10. LED Current vs Conduction Angle
11
