Bill of Materials (BOM) www.ti.com
3 Bill of Materials (BOM)
Table 1. Bill of Materials (BOM)
Designator Component Manufacturer
U1 LM3224MM, MSOP-8 Texas Instruments
L 4.7 µH, DO3316P-472 Coilcraft, [phone]
CIN 22 µF, JMK325BJ226MM Taiyo Yuden, [phone]
COUT 10 µF, TMK432BJ106MM Taiyo Yuden, [phone]
D 2A, 40 V Schottky, MBRS240LT On Semiconductor
RC 20k, 1206 Case, CRCW12062002F Dale (Vishay), [phone]
CC 1 nF, 1206 Case, VJ1206A102KXAA Vitramon (Vishay), [phone]
CC1, CSS Open
RFB1 20.5k, 1206 Case, CRCW12062052F Dale (Vishay), [phone]
RFB2 6.98k, 1206 Case, CRCW12066981F Dale (Vishay), [phone]
2
AN-1394 LM3224 Evaluation Board SNVA121A–January 2006–Revised April 2013
