LM3150
www.ti.com SNVS561D –SEPTEMBER 2008–REVISED MARCH 2011
Absolute Maximum Ratings
(1)(2)
VIN, RON to GND -0.3V to 47V
SW to GND -3V to 47V
BST to SW -0.3V to 7V
BST to GND -0.3V to 52V
All Other Inputs to GND -0.3V to 7V
ESD Rating
(3)
2 kV
Storage Temperature Range -65°C to +150°C
(1) Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for
which the device is intended to be functional, but does not ensure specific performance limits. For ensured specifications and conditions,
see the Electrical Characteristics.
(2) If Military/Aerospace specified devices are required, please contact the Texas Instruments Sales Office/ Distributors for availability and
specifications.
(3) The human body model is a 100 pF capacitor discharged through a 1.5 kΩ resistor into each pin. Test Method is per JESD-22-A114.
Operating Ratings
(1)
V
IN
6V to 42V
Junction Temperature Range (T
J
) −40°C to + 125°C
EN 0V to 5V
(1) Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for
which the device is intended to be functional, but does not ensure specific performance limits. For ensured specifications and conditions,
see the Electrical Characteristics.
Electrical Characteristics
Limits in standard type are for T
J
= 25°C only; limits in boldface type apply over the junction temperature (T
J
) range of -40°C
to +125°C. Minimum and Maximum limits are specified through test, design, or statistical correlation. Typical values represent
the most likely parametric norm at T
J
= 25°C, and are provided for reference purposes only. Unless otherwise stated the
following conditions apply: V
IN
= 18V.
Symbol Parameter Conditions Min Typ Max Units
Start-Up Regulator, VCC
VCC C
VCC
= 1 µF, 0 mA to 40 mA 5.65 5.95 6.25 V
I
VCC
= 2 mA, V
IN
= 5.5V 40
VIN - VCC VIN - VCC Dropout Voltage mV
I
VCC
= 30 mA, V
IN
= 5.5V 330
I
VCCL
VCC Current Limit
(1)
VCC = 0V 65 100 mA
VCC Under-Voltage Lockout Threshold
VCC
UVLO
VCC Increasing 4.75 5.1 5.40 V
(UVLO)
VCC
UVLO-HYS
VCC UVLO Hysteresis VCC Decreasing 475 mV
t
CC-UVLO-D
VCC UVLO Filter Delay 3 µs
I
IN
Input Operating Current No Switching, V
FB
= 1V 3.5 5 mA
I
IN-SD
Input Operating Current, Device Shutdown V
EN
= 0V 32 55 µA
GATE Drive
I
Q-BST
Boost Pin Leakage V
BST
– V
SW
= 6V 2 nA
R
DS-HG-Pull-Up
HG Drive Pull–Up On-Resistance I
HG
Source = 200 mA 5 Ω
R
DS-HG-Pull-Down
HG Drive Pull–Down On-Resistance I
HG
Sink = 200 mA 3.4 Ω
R
DS-LG-Pull-Up
LG Drive Pull–Up On-Resistance I
LG
Source = 200 mA 3.4 Ω
R
DS-LG-Pull-Down
LG Drive Pull–Down On-Resistance I
LG
Sink = 200 mA 2 Ω
Soft-Start
I
SS
SS Pin Source Current V
SS
= 0V 5.9 7.7 9.5 µA
I
SS-DIS
SS Pin Discharge Current 200 µA
Current Limit
I
LIM-TH
Current Limit Sense Pin Source Current 75 85 95 µA
(1) VCC provides self bias for the internal gate drive and control circuits. Device thermal limitations limit external loading.
