DRV2605
SLOS825B –DECEMBER 2012–REVISED JANUARY 2014
www.ti.com
WAVEFORM LIBRARY EFFECTS LIST
Effect ID# Waveform Name Effect ID# Waveform Name Effect ID# Waveform Name
1 Strong Click - 100% 42 Long Double Sharp Click Medium 2 – 80% 83 Transition Ramp Up Long Smooth 2 – 0 to 100%
2 Strong Click - 60% 43 Long Double Sharp Click Medium 3 – 60% 84 Transition Ramp Up Medium Smooth 1 – 0 to 100%
3 Strong Click - 30% 44 Long Double Sharp Tick 1 – 100% 85 Transition Ramp Up Medium Smooth 2 – 0 to 100%
4 Sharp Click - 100% 45 Long Double Sharp Tick 2 – 80% 86 Transition Ramp Up Short Smooth 1 – 0 to 100%
5 Sharp Click - 60% 46 Long Double Sharp Tick 3 – 60% 87 Transition Ramp Up Short Smooth 2 – 0 to 100%
6 Sharp Click - 30% 47 Buzz 1 – 100% 88 Transition Ramp Up Long Sharp 1 – 0 to 100%
7 Soft Bump - 100% 48 Buzz 2 – 80% 89 Transition Ramp Up Long Sharp 2 – 0 to 100%
8 Soft Bump - 60% 49 Buzz 3 – 60% 90 Transition Ramp Up Medium Sharp 1 – 0 to 100%
9 Soft Bump - 30% 50 Buzz 4 – 40% 91 Transition Ramp Up Medium Sharp 2 – 0 to 100%
10 Double Click - 100% 51 Buzz 5 – 20% 92 Transition Ramp Up Short Sharp 1 – 0 to 100%
11 Double Click - 60% 52 Pulsing Strong 1 – 100% 93 Transition Ramp Up Short Sharp 2 – 0 to 100%
12 Triple Click - 100% 53 Pulsing Strong 2 – 60% 94 Transition Ramp Down Long Smooth 1 – 50 to 0%
13 Soft Fuzz - 60% 54 Pulsing Medium 1 – 100% 95 Transition Ramp Down Long Smooth 2 – 50 to 0%
Transition Ramp Down Medium Smooth 1 – 50 to
14 Strong Buzz - 100% 55 Pulsing Medium 2 – 60% 96
0%
Transition Ramp Down Medium Smooth 2 – 50 to
15 750 ms Alert 100% 56 Pulsing Sharp 1 – 100% 97
0%
16 1000 ms Alert 100% 57 Pulsing Sharp 2 – 60% 98 Transition Ramp Down Short Smooth 1 – 50 to 0%
17 Strong Click 1 - 100% 58 Transition Click 1 – 100% 99 Transition Ramp Down Short Smooth 2 – 50 to 0%
18 Strong Click 2 - 80% 59 Transition Click 2 – 80% 100 Transition Ramp Down Long Sharp 1 – 50 to 0%
19 Strong Click 3 - 60% 60 Transition Click 3 – 60% 101 Transition Ramp Down Long Sharp 2 – 50 to 0%
20 Strong Click 4 - 30% 61 Transition Click 4 – 40% 102 Transition Ramp Down Medium Sharp 1 – 50 to 0%
21 Medium Click 1 - 100% 62 Transition Click 5 – 20% 103 Transition Ramp Down Medium Sharp 2 – 50 to 0%
22 Medium Click 2 - 80% 63 Transition Click 6 – 10% 104 Transition Ramp Down Short Sharp 1 – 50 to 0%
23 Medium Click 3 - 60% 64 Transition Hum 1 – 100% 105 Transition Ramp Down Short Sharp 2 – 50 to 0%
24 Sharp Tick 1 - 100% 65 Transition Hum 2 – 80% 106 Transition Ramp Up Long Smooth 1 – 0 to 50%
25 Sharp Tick 2 - 80% 66 Transition Hum 3 – 60% 107 Transition Ramp Up Long Smooth 2 – 0 to 50%
26 Sharp Tick 3 – 60% 67 Transition Hum 4 – 40% 108 Transition Ramp Up Medium Smooth 1 – 0 to 50%
27 Short Double Click Strong 1 – 100% 68 Transition Hum 5 – 20% 109 Transition Ramp Up Medium Smooth 2 – 0 to 50%
28 Short Double Click Strong 2 – 80% 69 Transition Hum 6 – 10% 110 Transition Ramp Up Short Smooth 1 – 0 to 50%
Transition Ramp Down Long Smooth 1 –
29 Short Double Click Strong 3 – 60% 70 111 Transition Ramp Up Short Smooth 2 – 0 to 50%
100 to 0%
Transition Ramp Down Long Smooth 2 –
30 Short Double Click Strong 4 – 30% 71 112 Transition Ramp Up Long Sharp 1 – 0 to 50%
100 to 0%
Transition Ramp Down Medium Smooth 1 –
31 Short Double Click Medium 1 – 100% 72 113 Transition Ramp Up Long Sharp 2 – 0 to 50%
100 to 0%
Transition Ramp Down Medium Smooth 2 –
32 Short Double Click Medium 2 – 80% 73 114 Transition Ramp Up Medium Sharp 1 – 0 to 50%
100 to 0%
Transition Ramp Down Short Smooth 1 –
33 Short Double Click Medium 3 – 60% 74 115 Transition Ramp Up Medium Sharp 2 – 0 to 50%
100 to 0%
Transition Ramp Down Short Smooth 2 –
34 Short Double Sharp Tick 1 – 100% 75 116 Transition Ramp Up Short Sharp 1 – 0 to 50%
100 to 0%
Transition Ramp Down Long Sharp 1 – 100
35 Short Double Sharp Tick 2 – 80% 76 117 Transition Ramp Up Short Sharp 2 – 0 to 50%
to 0%
Transition Ramp Down Long Sharp 2 – 100
36 Short Double Sharp Tick 3 – 60% 77 118 Long buzz for programmatic stopping – 100%
to 0%
Long Double Sharp Click Strong 1 – Transition Ramp Down Medium Sharp 1 –
37 78 119 Smooth Hum 1 (No kick or brake pulse) – 50%
100% 100 to 0%
Long Double Sharp Click Strong 2 – Transition Ramp Down Medium Sharp 2 –
38 79 120 Smooth Hum 2 (No kick or brake pulse) – 40%
80% 100 to 0%
Long Double Sharp Click Strong 3 – Transition Ramp Down Short Sharp 1 – 100
39 80 121 Smooth Hum 3 (No kick or brake pulse) – 30%
60% to 0%
Long Double Sharp Click Strong 4 – Transition Ramp Down Short Sharp 2 – 100
40 81 122 Smooth Hum 4 (No kick or brake pulse) – 20%
30% to 0%
Long Double Sharp Click Medium 1 – Transition Ramp Up Long Smooth 1 – 0 to
41 82 123 Smooth Hum 5 (No kick or brake pulse) – 10%
100% 100%
