DRV2605
www.ti.com SLOS825B –DECEMBER 2012–REVISED JANUARY 2014
Audio To Haptics Control (Address: 0x11)
Bit 7 6 5 4 3 2 1 0
Function ATH_PeakTime[1] ATH_PeakTime[0] ATH_Filter[1] ATH_Filter[0]
Type R/W R/W R/W R/W
Default 0 1 0 1
Audio To Haptics Minimum Input Level (Address: 0x12)
Bit 7 6 5 4 3 2 1 0
Function ATH_MinInput[7] ATH_MinInput[6] ATH_MinInput[5] ATH_MinInput[4] ATH_MinInput[3] ATH_MinInput[2] ATH_MinInput[1] ATH_MinInput[0]
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 0 0 0 1 1 0 0 1
Audio To Haptics Maximum Input Level (Address: 0x13)
Bit 7 6 5 4 3 2 1 0
Function ATH_MaxInput[7] ATH_MaxInput[6] ATH_MaxInput[5] ATH_MaxInput[4] ATH_MaxInput[3] ATH_MaxInput[2] ATH_MaxInput[1] ATH_MaxInput[0]
Type R/W R/W R/W R/W R/W R/W R/W R/W
Default 1 1 1 1 1 1 1 1
