Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)
DAC8162SDSCT WSON DSC 10 250 210.0 185.0 35.0
DAC8163SDGSR VSSOP DGS 10 2500 370.0 355.0 55.0
DAC8163SDGST VSSOP DGS 10 250 220.0 205.0 50.0
DAC8163SDSCR WSON DSC 10 3000 367.0 367.0 35.0
DAC8163SDSCT WSON DSC 10 250 210.0 185.0 35.0
DAC8562SDGSR VSSOP DGS 10 2500 370.0 355.0 55.0
DAC8562SDGST VSSOP DGS 10 250 220.0 205.0 50.0
DAC8562SDSCR WSON DSC 10 3000 367.0 367.0 35.0
DAC8562SDSCT WSON DSC 10 250 210.0 185.0 35.0
DAC8563SDGSR VSSOP DGS 10 2500 370.0 355.0 55.0
DAC8563SDGST VSSOP DGS 10 250 220.0 205.0 50.0
DAC8563SDSCR WSON DSC 10 3000 367.0 367.0 35.0
DAC8563SDSCT WSON DSC 10 250 210.0 185.0 35.0
PACKAGE MATERIALS INFORMATION
www.ti.com 24-Apr-2013
Pack Materials-Page 3
