Electrical Performance Specifications
3 Electrical Performance Specifications
Table 1. CSD86330EVM-717 Electrical Performance Specifications
PARAMETER TEST CONDITIONS MIN TYP MAX UNITS
Input Characteristics
Voltage range VIN 9 12 13.2 V
Maximum input current VIN = 9 V, I
O
= 10 A 1.6 A
No load input current V
IN
= 13.2 V, I
O
= 0 A 1 mA
Output Characteristics
Output voltage VOUT I
O
= 5 A 1.164 1.2 1.236 V
Output voltage regulation Line regulation(V
IN
= 9 V 13.2 V. I
O
=0 A - 10 A) 0.5%
Load regulation(V
IN
= 12 V, I
O
= 0 A - 10 A) 0.5%
Output voltage ripple V
IN
= 12 V, I
O
= 10 A 40 mV
PP
Output load current 0 10
A
Output over current 12
Systems Characteristics
Switching frequency 500 kHz
Peak efficiency V
IN
= 9 V, 1.2 V/5 A 92%
Full load efficiency V
IN
= 12 V, 1.2 V/10 A 89.4%
Operating temperature 25 °C
