DEVICE CHARACTERISTICS (Continued)
over recommended operating free-air temperature range (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP
(1)
MAX UNIT
CDCE949 – LVCMOS PARAMETER FOR V
DDOUT
= 3.3 V – MODE
V
DDOUT
= 3 V, I
OH
= –0.1 mA 2.9
V
OH
LVCMOS high-level output voltage V
DDOUT
= 3 V, I
OH
= –8 mA 2.4 V
V
DDOUT
= 3 V, I
OH
= –12 mA 2.2
V
DDOUT
= 3 V, I
OL
= 0.1 mA 0.1
V
OL
LVCMOS low-level output voltage V
DDOUT
= 3 V, I
OL
= 8 mA 0.5 V
V
DDOUT
= 3 V, I
OL
= 12 mA 0.8
t
PLH
,
Propagation delay PLL bypass 3.2 ns
t
PHL
t
r
/t
f
Rise and fall time V
DDOUT
= 3.3 V (20%–80%) 0.6 ns
1 PLL switching, Y2-to-Y3 60 90
t
jit(cc)
Cycle-to-cycle jitter
(2) (3)
ps
4 PLLs switching, Y2-to-Y9 120 170
1 PLL switching, Y2-to-Y3 70 100
t
jit(per)
Peak-to-peak period jitter
(2) (3)
ps
4 PLLs switching, Y2-to-Y9 130 180
f
OUT
= 50 MHz; Y1-to-Y3 60
t
sk(o)
Output skew
(4)
ps
f
OUT
= 50 MHz; Y2-to-Y5 or Y6-to-Y9 160
odc Output duty cycle
(5)
f
VCO
= 100 MHz; Pdiv = 1 45 55 %
CDCE949 – LVCMOS PARAMETER FOR V
DDOUT
= 2.5 V – MODE
V
DDOUT
= 2.3 V, I
OH
= –0.1 mA 2.2
V
OH
LVCMOS high-level output voltage V
DDOUT
= 2.3 V, I
OH
= –6 mA 1.7 V
V
DDOUT
= 2.3 V, I
OH
= –10 mA 1.6
V
DDOUT
= 2.3 V, I
OL
= 0.1 mA 0.1
V
OL
LVCMOS low-level output voltage V
DDOUT
= 2.3 V, I
OL
= 6 mA 0.5 V
V
DDOUT
= 2.3 V, I
OL
= 10 mA 0.7
t
PLH
,
Propagation delay PLL bypass 3.4 ns
t
PHL
t
r
/t
f
Rise and fall time V
DDOUT
= 2.5 V (20%–80%) 0.8 ns
1 PLL switching, Y2-to-Y3 60 90 ps
t
jit(cc)
Cycle-to-cycle jitter
(2) (3)
4 PLLs switching, Y2-to-Y9 120 170
1 PLL switching, Y2-to-Y3 70 100 ps
t
jit(per)
Peak-to-peak period jitter
(2) (3)
4 PLLs switching, Y2-to-Y9 130 180
f
OUT
= 50 MHz; Y1-to-Y3 60
t
sk(o)
Output skew
(4)
ps
f
OUT
= 50 MHz; Y2-to-Y5 or Y6-to-Y9 160
odc Output duty cycle
(5)
f
VCO
= 100 MHz; Pdiv = 1 45 55 %
(1) All typical values are at respective nominal V
DD
.
(2) 10000 cycles.
(3) Jitter depends on device configuration. Data is taken under the following conditions: 1-PLL: f
IN
= 27 MHz, Y2/3 = 27 MHz, (measured at
Y2), 4-PLL: f
IN
= 27 MHz, Y2/3 = 27 MHz, (manured at Y2), Y4/5 = 16.384 MHz, Y6/7 = 74.25 MHz, Y8/9 = 48 MHz.
(4) The t
sk(o)
specification is only valid for equal loading of each bank of outputs and outputs are generated from the same divider; data
sampled on rising edge (t
r
).
(5) odc depends on output rise- and fall-time (t
r
/t
f
).
