Datasheet

CDCE949
CDCEL949
SCAS844D –AUGUST 2007–REVISED MARCH 2010 www.ti.com
Table 13. PLL4 Configuration Register (continued)
OFFSET
(1)
Bit
(2)
Acronym Default
(3)
DESCRIPTION
48h 7:0 PLL4_0N [11:4 PLL4_0
(5)
: 30-Bit Multiplier/Divider value for frequency f
VCO4_0
004h
(for more information see paragraph PLL Multiplier/Divider Definition)
49h 7:4 PLL4_0N [3:0]
3:0 PLL4_0R [8:5]
000h
4Ah 7:3 PLL4_0R[4:0]
2:0 PLL4_0Q [5:3]
10h
4Bh 7:5 PLL4_0Q [2:0]
4:2 PLL4_0P [2:0] 010b
f
VCO4_0
range selection: 00 – f
VCO4_0
< 125 MHz
01 – 125 MHz ≤ f
VCO4_0
< 150 MHz
1:0 VCO4_0_RANGE 00b
10 – 150 MHz ≤ f
VCO4_0
< 175 MHz
11 – f
VCO4_0
≥ 175 MHz
4Ch 7:0 PLL4_1N [11:4] PLL4_1
(5)
: 30-Bit Multiplier/Divider value for frequency f
VCO4_1
004h
(for more information see paragraph PLL Multiplier/Divider Definition)
4Dh 7:4 PLL4_1N [3:0]
3:0 PLL4_1R [8:5]
000h
4Eh 7:3 PLL4_1R[4:0]
2:0 PLL4_1Q [5:3]
10h
4Fh 7:5 PLL4_1Q [2:0]
4:2 PLL4_1P [2:0] 010b
f
VCO4_1
range selection: 00 – f
VCO4_1
< 125 MHz
01 – 125 MHz ≤ f
VCO4_1
< 150 MHz
1:0 VCO4_1_RANGE 00b
10 – 150 MHz ≤ f
VCO4_1
< 175 MHz
11 – f
VCO4_1
≥ 175 MHz
(5) PLL settings limits: 16≤q≤63, 0≤p≤7, 0≤r≤511, 0<N<4096
