Table 10. PLL1 Configuration Register (continued)
OFFSET
(1)
Bit
(2)
Acronym Default
(3)
DESCRIPTION
18h 7:0 PLL1_0N [11:4 PLL1_0
(5)
: 30-Bit Multiplier/Divider value for frequency f
VCO1_0
004h
(for more information see PLL Multiplier/Divider Definition )
19h 7:4 PLL1_0N [3:0]
3:0 PLL1_0R [8:5]
000h
1Ah 7:3 PLL1_0R[4:0]
2:0 PLL1_0Q [5:3]
10h
1Bh 7:5 PLL1_0Q [2:0]
4:2 PLL1_0P [2:0] 010b
f
VCO1_0
range selection: 00 – f
VCO1_0
< 125 MHz
01 – 125 MHz ≤ f
VCO1_0
< 150 MHz
1:0 VCO1_0_RANGE 00b
10 – 150 MHz ≤ f
VCO1_0
< 175 MHz
11 – f
VCO1_0
≥ 175 MHz
1Ch 7:0 PLL1_1N [11:4] PLL1_1
(5)
: 30-Bit Multiplier/Divider value for frequency f
VCO1_1
004h
(for more information see paragraph PLL Multiplier/Divider Definition)
1Dh 7:4 PLL1_1N [3:0]
3:0 PLL1_1R [8:5]
000h
1Eh 7:3 PLL1_1R[4:0]
2:0 PLL1_1Q [5:3]
10h
1Fh 7:5 PLL1_1Q [2:0]
4:2 PLL1_1P [2:0] 010b
f
VCO1_1
range selection: 00 – f
VCO1_1
< 125 MHz
01 – 125 MHz ≤ f
VCO1_1
< 150 MHz
1:0 VCO1_1_RANGE 00b
10 – 150 MHz ≤ f
VCO1_1
< 175 MHz
11 – f
VCO1_1
≥ 175 MHz
(5) PLL settings limits: 16≤q≤63, 0≤p≤7, 0≤r≤511, 0<N<4096
