CDCE949
CDCEL949
www.ti.com
SCAS844D –AUGUST 2007–REVISED MARCH 2010
Table 10. PLL1 Configuration Register
OFFSET
(1)
Bit
(2)
Acronym Default
(3)
DESCRIPTION
10h 7:5 SSC1_7 [2:0] 000b SSC1: PLL1 SSC Selection (Modulation Amount)
(4)
4:2 SSC1_6 [2:0] 000b Down Center
000 (off) 000 (off)
1:0 SSC1_5 [2:1]
001 – 0.25% 001 ± 0.25%
000b
010 – 0.5% 010 ± 0.5%
11h 7 SSC1_5 [0]
011 – 0.75% 011 ± 0.75%
6:4 SSC1_4 [2:0] 000b
100 – 1.0% 100 ± 1.0%
101 – 1.25% 101 ± 1.25%
3:1 SSC1_3 [2:0] 000b
110 – 1.5% 110 ± 1.5%
0 SSC1_2 [2]
111 – 2.0% 111 ± 2.0%
000b
12h 7:6 SSC1_2 [1:0]
5:3 SSC1_1 [2:0] 000b
2:0 SSC1_0 [2:0] 000b
13h
7 FS1_7 0b
FS1_x: PLL1 Frequency Selection
(4)
6 FS1_6 0b 0 – f
VCO1_0
(predefined by PLL1_0 – Multiplier/Divider value)
1 – f
VCO1_1
(predefined by PLL1_1 – Multiplier/Divider value)
5 FS1_5 0b
4 FS1_4 0b
3 FS1_3 0b
2 FS1_2 0b
1 FS1_1 0b
0 FS1_0 0b
14h PLL1 Multiplexer: 0 – PLL1
7 MUX1 1b
1 – PLL1 Bypass (PLL1 is in power down)
Output Y2 Multiplexer: 0 – Pdiv1
6 M2 1b
1 – Pdiv2
Output Y3 Multiplexer: 00 – Pdiv1-Divider
01 – Pdiv2-Divider
5:4 M3 10b
10 – Pdiv3-Divider
11 – reserved
3:2 Y2Y3_ST1 11b Y2, Y3-State0/1definition: 00 – Y2/Y3 disabled to 3-State (PLL1 is in power down)
01 – Y2/Y3 disabled to 3-State (PLL1 on)
10–Y2/Y3 disabled to low (PLL1 on)
1:0 Y2Y3_ST0 01b
11 – Y2/Y3 enabled (normal operation, PLL1 on)
15h
7 Y2Y3_7 0b
Y2Y3_x Output State Selection
(4)
6 Y2Y3_6 0b 0 – state0 (predefined by Y2Y3_ST0)
1 – state1 (predefined by Y2Y3_ST1)
5 Y2Y3_5 0b
4 Y2Y3_4 0b
3 Y2Y3_3 0b
2 Y2Y3_2 0b
1 Y2Y3_1 1b
0 Y2Y3_0 0b
16h PLL1 SSC down/center selection: 0 – down
7 SSC1DC 0b
1 – center
7-Bit Y2-Output-Divider Pdiv2: 0 – reset and stand-by
6:0 Pdiv2 01h
1-to-127 – divider value
17h 7 — 0b Reserved – do not write others than 0
7-Bit Y3-Output-Divider Pdiv3: 0 – reset and stand-by
6:0 Pdiv3 01h
1-to-127 – divider value
(1) Writing data beyond 50h may adversely affect device function.
(2) All data is transferred MSB-first.
(3) Unless a custom setting is used
(4) The user can pre-define up to eight different control settings. In normal device operation, these settings can be selected by the external
control pins, S0, S1, and S2.
Copyright © 2007–2010, Texas Instruments Incorporated Submit Documentation Feedback 17
Product Folder Link(s): CDCE949 CDCEL949
