User's Manual



Figure2‐5:I
2
CConnectionsontheLAUNCHCC3220MODASF

ByremovingJ14andJ15,theaccelerometerandthetemperaturesensorsareisolatedfromtheI
2
Cbus.
NoethatthisstepalsoremovesanypullupresistorsfromtheI
2
Cbusandanysensorsconnectedtothe
busrequiresexternalpullups.

2.1.3 JumperSettings
Table2‐2liststhe I
2
Cconnectionjumpersettings.
Reference Usage Comments
J15 I2C SDA Short : Connect the CC3220MODASX I2C bus to the on-board sensors with pull-
up Open : Isolate the sensors from the CC3220
J14 I2C SCL Short : Connect the CC3220MODASX I2C bus to the on-board sensors with pull-
up Open : Isolate the sensors from the CC3220
Table2‐2:JumperSettings

2.1.4 DefaultI
2
CAddress
Table2‐3liststhe defaultI
2
Caddress.
Sensor Type Ref Part Number Slave Address
Temp sensor U10 TMP006 0x41
Accelerometer U11 BMA222E 0x18
Table2‐3:DefaultI
2
Caddress
