Task-Specific Program Code

C-22

Example C–14. Using Synchronous Serial Port With Codec Device (ad55.asm)

(Continued)

codtx: splk #0010h, ifr ; clear tx intr flag

clrc intm

ret

codrx: setc xf ; toggle xf bit

in *,sdtr ; Read ADC value

lacc *+,0 ; Make LSB zero

and #0fffeh,0 ; to avoid secondary

sacl 6ah,0 ; request for codec

out 6ah,sdtr ; Send ADC value to DAC

mar *,ar0

banz skip,ar1 ; Check buffer limits

lar ar1,#rxbuf

lar ar0,#size

skip: splk #0008h, ifr ; Clear ifr flag

clrc intm

ret

inpt1: ret

inpt23: ret

timer: ret

uart: ret

.end ; Assembler module end directive

; –optional
