Example C–9. Asynchronous Serial Port Transmission (uart.asm) (Continued)

lar ar1,#rxbuf

lar ar0, #20 ; load buffer size

mar *,ar1 ; load data pointer

clrc intm

wait: clrc xf ; toggle xf bit

idle

b wait

uart: setc xf ; toggle xf bit

splk #0ffffh,67h

out *+,adtr ; transmit character from data buffer@300

mar *,ar0

banz skip,ar1 ; check if size=0, and reload

lar ar1,#rxbuf

lar ar0,#20 ; set size = character length

skip: splk #0020h,ifr ; Clear ifr bit

clrc intm

ret

inpt1: ret

inpt23: ret

timer: ret

codtx: ret

codrx: ret

.end ; Assembler module end directive

; –optional

Example C–10. Loopback to Verify Transmissions of Asynchronous Serial Port (echo.asm)

* File: echo.asm *

* Function: UART Test Code *

* Continuously echoes data received by UART at 1200 baud. *

* Received data will be stored in the buffer @300 *

.title ” UART/ASP loop back” ; Title

.copy ”init.h” ; Variable and register declaration

.copy ”vector.h” ; Vector label declaration

.text

start: clrc CNF ; Map block B0 to data memory

ldp #0h ; set DP=0

setc INTM ; Disable all interrupts
