Instruction Set Comparison Table
B-25
TMS320C1x/C2x/C2xx/C5x Instruction Set Comparison
Syntax
Description5x2xx2x1x
OR
dma
OR {
ind
} [
, next ARP
]
OR #
lk
[
, shift
]
√
√
√
√
√
√
√
√
√
√
OR With Accumulator
TMS320C1x and TMS320C2x devices: OR the 16
LSBs of the accumulator with the contents of the ad-
dressed data-memory location. The 16 MSBs of the
accumulator are ORed with 0s.
TMS320C2xx and TMS320C5x devices: OR the 16
LSBs of the accumulator or a 16-bit immediate value
with the contents of the addressed data-memory loca-
tion. If a shift is specified, left-shift before ORing. Low-
order bits below and high-order bits above the shifted
value are treated as 0s.
ORB
√
OR ACCB With Accumulator
OR the contents of the ACCB with the contents of the
accumulator. ORB places the result in the accumula-
tor.
ORK #
lk
[
, shift
]
√ √ √
OR Immediate With Accumulator with Shift
OR a 16-bit immediate value with the contents of the
accumulator. If a shift is specified, left-shift the con-
stant before ORing. Low-order bits below and high-
order bits above the shifted value are treated as 0s.
OUT
dma, PA
OUT {
ind
}
, PA
[
, next ARP
]
√
√
√
√
√
√
√
√
Output Data to Port
Write a 16-bit value from a data-memory location to the
specified I/O port.
TMS320C1x devices: The first cycle of this instruction
places the port address onto address lines
A2/PA2–A0/PA0. During the same cycle, WE goes low
and the data word is placed on the data bus D15–D0.
TMS320C2x, TMS320C2xx, and TMS320C5x de-
vices: The IS
line goes low to indicate an I/O access;
the STRB
, R/W, and READY timings are the same as
for an external data-memory write.
PAC
√ √ √ √
Load Accumulator With P Register
Load the contents of the P register into the accumula-
tor.
TMS320C2x, TMS320C2xx, and TMS320C5x de-
vices: Before the load, shift the P register as specified
by the PM status bits.
POP
√ √ √ √
Pop Top of Stack to Low Accumulator
Copy the contents of the top of the stack into the 12
(TMS320C1x) or 16 (TMS320C2x/2xx/5x) LSBs of the
accumulator and then pop the stack one level. The
MSBs of the accumulator are zeroed.
