Enhanced Instructions

B-5

TMS320C1x/C2x/C2xx/C5x Instruction Set Comparison

B.2 Enhanced Instructions

An enhanced instruction is a single mnemonic that performs the functions of

several similar instructions. For example, the enhanced instruction ADD

performs the ADD, ADDH, ADDK, and ADLK functions and replaces any of

these other instructions at assembly time. For example, when a program using

ADDH is assembled for the ’C2xx or ’C5x, ADDH is replaced by an ADD

instruction that performs the same function. These enhanced instructions are

valid for TMS320C2x, TMS320C2xx, and TMS320C5x devices (not

TMS320C1x).

Table B–2 below summarizes the enhanced instructions and the functions that

the enhanced instructions perform (based on TMS320C1x/2x mnemonics).

Table B–2. Summary of Enhanced Instructions

Enhanced

Instruction

Includes These Operations

ADD

ADD, ADDH, ADDK, ADLK

AND

AND, ANDK

BCND BBNZ, BBZ, BC, BCND, BGEZ, BGZ, BIOZ, BLEZ, BLZ,

BNC, BNV, BNZ, BV, BZ

BLDD BLDD, BLKD

BLDP BLDP, BLKP

CLRC

CLRC, CNFD, EINT, RC, RHM, ROVM, RSXM, RTC,

RXF

LACC LAC, LACC, LALK, ZALH

LACL LACK, LACL, ZAC, ZALS

LAR LAR, LARK, LRLK

LDP LDP, LDPK

LST LST, LST1

MAR LARP, MAR

MPY MPY, MPYK

OR OR, ORK

RPT RPT, RPTK

SETC CNFP, DINT, SC, SETC, SHM, SOVM, SSXM, STC, SXF

SUB SUB, SUBH, SUBK
