’C209 Interrupts

11-12

Figure 11–2.’C209 Interrupt Flag Register (IFR) — Data-Memory Address 0006h

15 4 3 2 1 0

Reserved TINT INT3 INT2 INT1

0 R/W1C–0 R/W1C–0 R/W1C–0 R/W1C–0

Note: 0 = Always read as zeros; R = Read access; W1C = Write 1 to this bit to clear it to 0;

value following dash (–) is value after reset.

Bits 15–4 Reserved. Bits 15–4 are reserved and are always read as 0s.

Bit 3 TINT — Timer interrupt flag. Bit 3 indicates whether interrupt TINT is pending

(whether TINT is requesting acknowledgment from the CPU).

TINT = 0 Interrupt TINT is not pending.

TINT = 1 Interrupt TINT is pending.

Bit 2 INT3 — Interrupt 3 flag. Bit 2 indicates whether INT3

is pending (whether INT3 is

requesting acknowledgment from the CPU).

INT3 = 0 INT3

is not pending.

INT3 = 1 INT3

is pending.

Bit 1 INT2 — Interrupt 2 flag. Bit 1 indicates whether INT2

is pending (whether INT2 is

requesting acknowledgment from the CPU).

INT2 = 0 INT2

is not pending.

INT2 = 1 INT2

is pending.

Bit 0 INT1 — Interrupt 1 flag. Bit 0 indicates whether INT1

is pending (whether INT1 is

requesting acknowledgment from the CPU).

INT1 = 0 INT1

is not pending.

INT1 = 1 INT1

is pending.
