SPAC

Subtract PREG From Accumulator

7-160

Syntax SPAC

Operands None

Opcode

0123456789101112131415

1010000001111101

Execution Increment PC, then ...

(ACC) – shifted (PREG) → ACC

Status Bits

Affected by Affects

PM and OVM C and OV

This instruction is not affected by SXM.

Description The content of PREG, shifted as defined by the PM status bits, is subtracted

from the content of the accumulator. The result is stored in the accumulator.

SPAC is not affected by SXM, and the PREG value is always sign extended.

The function of the SPAC instruction is a subtask of the LTS, MPYS, and SQRS

instructions.

Words 1

Cycles for a Single SPAC Instruction

ROM

DARAM SARAM External

1 1 1 1+p

Cycles for a Repeat (RPT) Execution of an SPAC Instruction

ROM

DARAM SARAM External

n n n n+p

Example SPAC ;(PM = 0)

Before Instruction After Instruction

PREG 10000000h PREG 10000000h

ACC X 70000000h ACC 1 60000000h

Cycles
