Set Control Bit

SETC

7-155

Assembly Language Instructions

Syntax SETC

control bit

Operands control bit: Select one of the following control bits:

C Carry bit of status register ST1

CNF RAM configuration control bit of status register ST1

INTM Interrupt mode bit of status register ST0

OVM Overflow mode bit of status register ST0

SXM Sign-extension mode bit of status register ST1

TC Test/control flag bit of status register ST1

XF XF pin status bit of status register ST1

SETC C

0123456789101112131415

1111001001111101

SETC CNF

0123456789101112131415

1010001001111101

SETC INTM

0123456789101112131415

1000001001111101

SETC OVM

0123456789101112131415

1100001001111101

SETC SXM

0123456789101112131415

1110001001111101

SETC TC

0123456789101112131415

1101001001111101

SETC XF

0123456789101112131415

1011001001111101

Execution Increment PC, then ...

1 → control bit

Status Bits None

Description The specified control bit is set to 1. Note that LST may also be used to load

ST0 and ST1. See Section 3.5,

Status and Control Registers

, on page 3-15

for more information on each control bit.
