SAR

Store Auxiliary Register

7-152

Syntax SAR AR

dma

Direct addressing

SAR AR

ind [, AR

] Indirect addressing

Operands dma: 7 LSBs of the data-memory address

x: Value from 0 to 7 designating the auxiliary register value to be

stored

n: Value from 0 to 7 designating the next auxiliary register

ind: Select one of the following seven options:

* *+ *– *0+ *0– *BR0+ *BR0–

SAR AR

dma

1514131211109876543210

0000 x 0 dma

SAR AR

ind

[

]

1514131211109876543210

0000 x 0 ARU N NAR

Note: ARU, N, and NAR are defined in Section 6.3,

Indirect Addressing Mode

(page 6-9).

Execution Increment PC, then ...

(ARx) → data-memory address

Status Bits None

Description The content of the designated auxiliary register (ARx) is stored in the specified

data-memory location. When the content of the designated auxiliary register

is also modified by the instruction (in indirect addressing mode), SAR copies

the auxiliary register value to data memory before it increments or decrements

the contents of the auxiliary register.

Words 1

Cycles for a Single SAR Instruction

Program

Operand ROM DARAM SARAM External

DARAM 1 1 1 1+p

SARAM 1 1 1, 2

†

1+p

External 2+d 2+d 2+d 4+d+p

†

If the operand and the code are in the same SARAM block

Opcode

Cycles
