Branch Unconditionally

7-39

Assembly Language Instructions

Syntax B

pma

ind

[, AR

]] Indirect addressing

Operands pma: 16-bit program-memory address

n: Value from 0 to 7 designating the next auxiliary register

ind: Select one of the following seven options:

* *+ *– *0+ *0– *BR0+ *BR0–

pma

ind

[

]]

1514131211109876543210

11110011 ARU N NAR

pma

Note: ARU, N, and NAR are defined in Section 6.3,

Indirect Addressing Mode

(page 6-9).

Execution pma → PC

Modify (current AR) and (ARP) as specified.

Status Bits None

Description The current auxiliary register and ARP contents are modified as specified, and

control is passed to the designated program-memory address (pma). The pma

can be either a symbolic or numeric address.

Words 2

Cycles for a Single B Instruction

ROM DARAM SARAM External

4 4 4 4+4p

Note: When this instruction reaches the execute phase of the pipeline, two additional instruc-

tion words have entered the pipeline. When the PC discontinuity is taken, these two

instruction words are discarded.

Example B 191,*+,AR1

The value 191 is loaded into the program counter, and the program continues

to execute from that location. The current auxiliary register is incremented by

1, and ARP is set to point to auxiliary register 1 (AR1).

Opcode

Cycles
