Add PREG to Accumulator

APAC

7-37

Assembly Language Instructions

Syntax APAC

Operands None

APAC

1514131211109876543210

011111000000100

Execution Increment PC, then ...

(ACC) + shifted (PREG) → ACC

Status Bits

Affected by Affects

PM and OVM C and OV

This instruction is not affected by SXM.

Description The contents of PREG are shifted as defined by the PM status bits of the ST1

sult is placed in the accumulator. APAC is not affected by the SXM bit of the

status register. PREG is always sign extended. The task of the APAC instruc-

tion is also performed as a subtask of the LTA, LTD, MAC, MACD, MPYA, and

SQRA instructions.

Table 7–7. Product Shift Modes

PM Bits

Bit 1 Bit 0

Resulting Shift

0 No shift

0 1 Left shift of 1 bit

1 0 Left shift of 4 bits

1 Right shift of 6 bits

Words 1

Cycles for a Single APAC Instruction

ROM

DARAM SARAM External

1 1 1 1+p

Cycles for a Repeat (RPT) Execution of an APAC Instruction

ROM DARAM SARAM External

n n n n+p

Opcode

Cycles
