Absolute Value of Accumulator

ABS

7-21

Assembly Language Instructions

Syntax ABS

Operands None

Opcode

0123456789101112131415

0000000001111101

Execution Increment PC, then ...

|(ACC)| → ACC; 0 → C

Status Bits

Affected by Affects

OVM C and OV

This instruction is not affected by SXM

Description If the contents of the accumulator are greater than or equal to zero, the accu-

mulator is unchanged by the execution of ABS. If the contents of the accumula-

tor are less than zero, the accumulator is replaced by its 2s-complement value.

The carry bit (C) on the ’C2xx is always reset to zero by the execution of this

instruction.

Note that 8000 0000h is a special case. When the overflow mode is not set

(OVM = 0), the ABS of 8000 0000h is 8000 0000h. When the overflow mode

is set (OVM = 1), the ABS of 8000 0000h is 7FFF FFFFh. In either case, the

OV status bit is set.

Words 1

Cycles for a Single ABS Instruction

ROM

DARAM SARAM External

1 1 1 1+p

Cycles for a Repeat (RPT) Execution of an ABS Instruction

ROM

DARAM SARAM External

n n n n+p

Cycles
