How To Use the Instruction Descriptions

7-12

7.2 How To Use the Instruction Descriptions

Section 7.3 contains detailed information on the instruction set. The descrip-

tion for each instruction presents the following categories of information:

Syntax

Operands

Opcode

Execution

Status Bits

Description

Words

Cycles

Examples

7.2.1 Syntax

Each instruction begins with a list of the available assembler syntax expres-

sions and the addressing mode type(s) for each expression. For example, the

description for the ADD instruction begins with:

ADD

dma

shift

] Direct addressing

ADD

dma

, 16 Direct with left shift of 16

ADD

ind

shift

[, AR

]] Indirect addressing

ADD

ind

, 16 [, AR

] Indirect with left shift of 16

ADD #

Short immediate addressing

ADD #

shift

] Long immediate addressing

These are the notations used in the syntax expressions:

italic

symbols

Italic symbols in an instruction syntax represent variables.

Example:

For the syntax:

ADD

dma

you may use a variety of values for

dma

Samples with this syntax follow:

ADD DAT

ADD 15

boldface

characters

Boldface characters in an instruction syntax must be typed as

shown.

Example:

For the syntax:

ADD

dma

, 16

you may use a variety of values for

dma

, but the

word ADD and the number 16 should be typed

as shown. Samples with this syntax follow:

ADD 7h, 16

ADD X, 16
