Instruction Set Summary

7-8

Table 7–3. TREG, PREG, and Multiply Instructions (Continued)

Mnemonic OpcodeCyclesWordsDescription

MAC Multiply and accumulate, direct or indirect 2 3 1010 0010 IAAA AAAA

+ 1 word

MACD Multiply and accumulate with data move, direct or

indirect

2 3 1010 0011 IAAA AAAA

+ 1 word

MPY Multiply TREG by data value, direct or indirect 1 1 0101 0100 IAAA AAAA

Multiply TREG by 13-bit constant, short immediate 1 1 110I IIII IIII IIII

MPYA Multiply and accumulate previous product, direct or

indirect

1 1 0101 0000 IAAA AAAA

MPYS Multiply and subtract previous product, direct or in-

direct

1 1 0101 0001 IAAA AAAA

MPYU Multiply unsigned, direct or indirect 1 1 0101 0101 IAAA AAAA

PAC Load ACC with PREG 1 1 1011 1110 0000 0011

SPAC Subtract PREG from ACC 1 1 1011 1110 0000 0101

SPH Store high PREG, direct or indirect 1 1 1000 1101 IAAA AAAA

SPL Store low PREG, direct or indirect 1 1 1000 1100 IAAA AAAA

SPM Set product shift mode 1 1 1011 1111 0000 00PM

SQRA Square and accumulate previous product, direct or

indirect

1 1 0101 0010 IAAA AAAA

SQRS

Square and subtract previous product, direct or

indirect

1 1 0101 0011 IAAA AAAA

Table 7–4. Branch Instructions

Mnemonic Description Words Cycles Opcode

B Branch unconditionally, indirect 2 4 0111 1001 1AAA AAAA

+ 1 word

BACC Branch to address specified by

ACC

1 4 1011 1110 0010 0000

BANZ Branch on current AR not-zero,

indirect

2 4 (condition true)

2 (condition false)

0111 1011 1AAA AAAA

+ 1 word

BCND Branch conditionally 2 4 (conditions true)

2 (any condition false)

1110 00TP ZLVC ZLVC

+ 1 word

CALA

Call subroutine at location

specified by ACC

1 4 1011 1110 0011 0000
