Instruction Set Summary

7-7

Assembly Language Instructions

Table 7–2. Auxiliary Register Instructions

Mnemonic Description Words Cycles Opcode

ADRK Add constant to current AR,

short immediate

1 1 0111 1000 IIII IIII

BANZ Branch on current AR not-zero,

indirect

2 4 (condition true)

2 (condition false)

0111 1011 1AAA AAAA

+ 1 word

CMPR Compare current AR with AR0 1 1 1011 1111 0100 01CM

LAR

Load specified AR from

specified data location,

direct or indirect

1 2 0000 0ARX IAAA AAAA

Load specified AR with

constant, short immediate

1 2 1011 0ARX IIII IIII

Load specified AR with

constant, long immediate

2 2 1011 1111 0000 1ARX

+ 1 word

MAR Modify current AR and/or ARP,

indirect (performs no operation

when direct)

1 1 1000 1011 IAAA AAAA

SAR Store specified AR to specified

data location, direct or indirect

1 1 1000 0ARX IAAA AAAA

SBRK

Subtract constant from current

AR, short immediate

1 1 0111 1100 IIII IIII

Table 7–3. TREG, PREG, and Multiply Instructions

Mnemonic Description Words Cycles Opcode

APAC Add PREG to ACC 1 1 1011 1110 0000 0100

LPH Load high PREG, direct or indirect 1 1 0111 0101 IAAA AAAA

LT Load TREG, direct or indirect 1 1 0111 0011 IAAA AAAA

LTA Load TREG and accumulate previous product,

direct or indirect

1 1 0111 0000 IAAA AAAA

LTD Load TREG, accumulate previous product, and

move data, direct or indirect

1 1 0111 0010 IAAA AAAA

LTP Load TREG and store PREG in accumulator,

direct or indirect

1 1 0111 0001 IAAA AAAA

LTS

Load TREG and subtract previous product,

direct or indirect

1 1 0111 0100 IAAA AAAA
