Reset Operation

5-35

Program Control

Table 5–6. Reset Values of On-Chip Registers Mapped to Data Space

Name Data-Memory Address Reset Value Description

IMR 0004h 0000h Interrupt mask register

GREG 0005h 0000h Interrupt control register

IFR

0006h 0000h Synchronous data transmit and receive register

Table 5–7. Reset Values of On-Chip Registers Mapped to I/O Space

I/O Address

Name ’C209 Other ’C2xx Reset Value Description

CLK

– FFE8h 0000h CLKOUT1-pin control (CLK) register

ICR – FFECh 0000h Interrupt control register

SDTR – FFF0h xxxxh Synchronous data transmit and receive register

SSPCR – FFF1h 0030h Synchronous serial port control register

ADTR – FFF4h xxxxh Asynchronous data transmit and receive register

ASPCR – FFF5h 0000h Asynchronous serial port control register

IOSR – FFF6h 18xxh I/O status register

BRD – FFF7h 0001h Baud-rate divisor register

TCR FFFCh FFF8h 0000h Timer control register

PRD FFFDh FFF9h FFFFh Timer period register

TIM FFFEh FFFAh FFFFh Timer counter register

WSGR FFFFh FFFCh 0FFFh Wait-state generator control register

Note: An x in an address represents four bits that are either not affected by reset or dependent on pin levels at reset.
