switching characteristics over recommended operating free-air temperature range,
V
CC
= 5 V ± 0.5 V (unless otherwise noted) (see Figure 1)
PARAMETER
FROM
TO
LOAD
T
A
= 25°C -40°C TO 85°C -40°C TO 125°C
UNIT
PARAMETER
FROM
(INPUT)
TO
(OUTPUT)
LOAD
CAPACITANCE
MIN TYP MAX MIN MAX MIN MAX
UNIT
t
PLH
A or B
Y
C
L
= 15 pF
5 6.9 1 8 9.5
ns
t
PHL
A or B Y C
L
= 15 pF
5 6.9 1 8 9.5
ns
t
PLH
A or B
Y
C
L
= 50 pF
5.5 7.9 1 9 10.5
ns
t
PHL
A or B
Y
C
L
= 50 pF
5.5 7.9 1 9 10.5
ns
operating characteristics, V
CC
= 5 V, T
A
= 25°C
PARAMETER TEST CONDITIONS TYP UNIT
C
pd
Power dissipation capacitance No load, f = 1 MHz 11.5 pF
