6.2 Recommended Land Pattern
BlueMod+B20
top view
14,5
16,58
1,275
1,275
28
15,1
1,3
1,3
0,9
1,675
0,3
0,3
1,825
2,7
3,5
Figure 6.2 BlueMod+B20 land pattern
