5 Electrical Characteristics
5.1 Absolute Maximum Ratings
Stresses beyond those listed under “Absolute Maximum Ratings” may cause per-
manent damage to the device. These are stress ratings only, and functional opera-
tion of the device at these or any other conditions beyond those indicated under
“Electrical Requirements” is not implied. Exposure to absolute-maximum-rated con-
ditions for extended periods may affect device reliability.
Item Symbol Absolute Maximum Ratings Unit
Supply voltage V
SUP
-0.4 to +3.7 V
Voltage on any pin V
Pin
GND -0.3 to VSUP +0.4 V
5.2 Electrical Requirements
VSUP = 3.3V, T
amb
= 25°C if nothing else stated
Item Condition Limit Unit
Min Typ Max
Frequency Range 2400 2483.5 MHz
Load impedance
Measured with network
analyzer in the frequency
range at antenna pin
50 Ohm
Output return loss
Receive Mode to 50Ω
load
Transmit Mode to 50Ω
load
-10
-10
dBm
Supply voltage
VSUP
The typical voltage is
recommended VSUP at
voltage pin
2.8 3.3 3.6 Vdc
Ripple on Vcc
Ripple frequency
≤10MHz
10 mVrms
5.3 Environmental Requirements
Item
Sym-
bol
Absolute Maximum Ratings Unit
Storage temperature range T
stg
-40 to +105 °C
Operating temperature
range
T
op
-40 to +85 °C
