LM940 HW Design Guide

1VV0301352 Rev. 2 Page 64 of 68 2017-07-19

Mode Freq. Tx

(MHz)

Freq. Rx

(MHz)

Channels Tx-Rx

Offset

LTE 700b – B17 704 ~ 716 734 ~ 746 Tx: 23730 ~ 23849

Rx: 5730 ~ 5849

30 MHz

LTE 800 – B20 832 ~ 862 791 ~ 821 Tx: 24150 ~ 24449

Rx: 6150 ~ 6449

-41 MHz

LTE 1900+ – B25 1850 ~ 1915 1930 ~ 1995 Tx: 8040 ~ 8689

Rx: 26040 ~ 26689

80 MHz

LTE 850+ – B26 814 ~ 849 859 ~ 894 Tx: 8690 ~ 9039

Rx: 26690 ~ 27039

45 MHz

LTE 700 APT –

B28

703 ~ 748 758 ~ 803 Tx: 9210 ~ 9659

Rx: 27210 ~ 27659

55 MHz

LTE 700 d – B29 Downlink

only

717 ~ 728 Rx: 9660 ~ 9769 –

LTE 2300 WCS –

B30

2305 ~ 2315 2350 ~ 2360 Tx: 9770 ~ 9869

Rx: 27660 ~ 27759

45 MHz

LTE AWS-3 – B66 1710 ~ 1780 2110 ~ 2200 Tx: 66436 ~ 67335

Rx: 131972 ~

132671

400 MHz

LTE TDD 2600 –

B38

2570 ~ 2620 2570 ~ 2620 Tx: 37750 ~ 38250

Rx: 37750 ~ 38250

0 MHz

LTE TDD 2300 –

B40

2300 ~ 2400 2300 ~ 2400 Tx: 38650 ~ 39650

Rx: 38650 ~ 39650

0 MHz

LTE TDD 2500 –

B41

2496 ~ 2690 2496 ~ 2690 Tx: 39650 ~ 41589

Rx: 39650 ~ 41589

0 MHz
