14. REFERENCE TABLE OF RF BANDS CHARACTERISTICS

RF Bands Characteristics

Mode Freq. Tx

(MHz)

Freq. Rx

(MHz)

Channels Tx-Rx

Offset

WCDMA 2100 –

1920 ~ 1980 2110 ~ 2170 Tx: 9612 ~ 9888

Rx: 10562 ~ 10838

190 MHz

WCDMA 1900 –

1850 ~ 1910 1930 ~ 1990 Tx: 9262 ~ 9538

Rx: 9662 ~ 9938

80 MHz

WCDMA AWS –

1710 ~ 1755 2110 ~ 2155 Tx: 1537 ~ 1738

Rx: 1312 ~ 1513

400 MHz

WCDMA 850 – B5 824 ~ 849 869 ~ 894 Tx: 4132 ~ 4233

Rx: 4357 ~ 4458

45 MHz

WCDMA 900 – B8 880 ~ 915 925 ~ 960 Tx: 2712 ~ 2863

Rx: 2937 ~ 3088

45 MHz

LTE 2100 – B1 1920 ~ 1980 2110 ~ 2170 Tx: 18000 ~ 18599

Rx: 0 ~ 599

190 MHz

LTE 1900 – B2 1850 ~ 1910 1930 ~ 1990 Tx: 18600 ~ 19199

Rx: 600 ~ 1199

80 MHz

LTE 1800+ – B3 1710 ~ 1785 1805 ~ 1880 Tx: 19200 ~ 19949

Rx: 1200 ~ 1949

95 MHz

LTE AWS-1 – B4 1710 ~ 1755 2110 ~ 2155 Tx: 19950 ~ 20399

Rx: 1950 ~ 2399

400 MHz

LTE 850 – B5 824 ~ 849 869 ~ 894 Tx: 20400 ~ 20649

Rx: 2400 ~ 2649

45 MHz

LTE 2600 – B7 2500 ~ 2570 2620 ~ 2690 Tx: 20750 ~ 21449

Rx: 2750 ~ 3449

120 MHz

LTE 900 – B8 880 ~ 915 925 ~ 960 Tx: 21450 ~ 21799

Rx: 3450 ~ 3799

45 MHz

LTE 700a – B12 699 ~ 716 729 ~ 746 Tx : 23010 ~ 23179

Rx : 5010 ~ 5179

30 MHz

LTE 700c – B13 777 ~ 787 746 ~ 756 Tx : 27210 ~ 27659

Rx : 9210 ~ 9659

-31 MHz
