6. DIGITAL SECTION
Logic Levels
Unless otherwise specified, all the interface circuits of the LM940 are 1.8V CMOS logic.
Only USIM interfaces are capable of dual voltage I/O.
The following tables show the logic level specifications used in the LM940 interface
circuits. The data specified in the tables below is valid throughout all drive strengths and
the entire temperature ranges.
Caution – Do not connect LM940’s digital logic signal directly to
OEM’s digital logic signal with a level higher than 2.3V for 1.8V
CMOS signals.
6.1.1. 1.8V Pins – Absolute Maximum Ratings
Absolute Maximum Ratings – Not Functional
Parameter Min Max
Input level on any digital pin when on -- +2.16V
Input voltage on analog pins when on -- +2.16 V
6.1.2. 1.8V Standard GPIOs
Operating Range – Interface Levels (1.8V CMOS)
Parameter Min Max Unit Comment
VIH Input high level 1.17V 2.1V [V]
VIL Input low level -0.3V 0.63V [V]
VOH Output high level 1.35V 1.8V [V]
VOL Output low level 0V 0.45V [V]
IIL Low-level input leakage
current
-1 -- [uA] No pull-up
IIH High-level input leakage
current
-- 1 [uA] No pull-down
IILPU Low-level input leakage
current
-97.5 -27.5 [uA] With pull-up
