Australia B1+B3, B1+B7, B1+B28, B3+B8, B3+B28, B5+B7, B5+B40, B7+B8,
B7+B20
LTE 3DL carrier aggregation combinations
North
America
B2+B2+B12/17, B2+B2+B13, B2+B2+B4, B2+B4+B5, B2+B4+B12,
B2+B4+B13, B2+B4+B29, B2+B5+B30, B2+B12+B12, B2+B12+B30,
B2+B29+B30, B4+B4+B5, B4+B4+B7, B4+B4+B12, B4+B4+B13,
B4+B5+B30, B4+B12+B12, B4+B12+B30, B4+B29+B30, B25+B26+B41,
B25+B41+B41, B26+B41+B41, B41+B41+B41
Europe B1+B3+B20, B1+B7+B20, B3+B3+B7, B3+B3+B20, B3+B7+B20,
B3+B7+B7, B3+B20+B38, B3+B38+B38
Australia B3+B3+B5, B3+B3+B8, B3+B7+B7, B3+B7+B28, B7+B7+B28,
B28+B40+B40, B40+B40+B40
Refer to Chapter 13 for details information about frequencies and bands.
Target market
LM940 can be used for telematics applications where tamper-resistance, confidentiality,
integrity, and authenticity of end-user information are required, for example:
 Mobile router
 Industrial equipment
 Home network
 Internet connectivity
Main features
The LM940 family of industrial grade cellular modules features LTE and multi-RAT module
together with an on-chip powerful application processor and a rich set of interfaces.
The major functions and features are listed below.
Main Features
Function Features
Module
 Multi-RAT cellular module for data communication
o LTE FDD/TDD Cat11(600/75 Mbps DL/UL)
o WCDMA up to DC HSPA+, Rel.9
 Support for GPS, GLONASS, BeiDou, Galileo
Audio
subsystem
 Support digital audio interface (optional)
