2. GENERAL PRODUCT DESCRIPTION
Overview
The aim of this document is to present possible and recommended hardware solutions
useful for developing a product with the Telit LM940 Mini PCIe module.
LM940 is Telit’s platform for Mini PCIe module for applications, such as M2M applications,
industrial mobile router and table PC, based on the following technologies:
LTE / WCDMA networks for data communication
Designed for industrial grade quality
In its most basic use case, LM940 can be applied as a wireless communication front-end
for mobile router products, offering mobile communication features to an external host
CPU through its rich interfaces.
LM940 can further support customer software applications and security features. LM940
provides a software application development environment with sufficient system resources
for creating rich on-board applications. Thanks to a dedicated application processor and
embedded security resources, product developers and manufacturers can create products
that guarantee fraud prevention and tamper evidence without extra effort for additional
security precautions.
LM940 is available in hardware variants as listed in Applicability Table
The designated RF band sets per each variant are detailed in Section 2.2, Product
Variants and Frequency Bands.
Product Variants and Frequency Bands
The operating frequencies in LTE & WCDMA modes conform to the 3GPP specifications.
2.2.1. RF Bands per Regional Variant
This table summarizes the LM940, showing the supported band sets and the supported
band pairs and triple for carrier aggregation.
RF Bands and Carrier Aggregation
LTE FDD LTE TDD HSPA+
Bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 20, 25, 26, 28, 29,
30, 66
38, 40, 41 1, 2, 4, 5, 8
GNSS GPS, GLONASS, BeiDou, Galileo
LTE 2DL carrier aggregation combinations
North
America
B2+B2, B2+B4, B2+B5, B2+B12, B2+B13, B2+B17, B2+B29, B2+B30,
B4+B4, B4+B5, B4+B7, B4+B12, B4+B13, B4+B17, B4+B29, B4+B30,
B5+B30, B12+B12, B12+B30, B25+B25, B25+B26, B25+B41, B26+B41,
B29+B30, B41+B41
Europe B1+B20, B3+B3, B3+B7, B3+B20, B3+B38, B7+B7, B7+B8, B7+B20,
B38+B38
