TECHNICAL MANUAL
Telit GM862 PCS
Tri Band GPRS Data Terminal System Rev.1
48 GPIO5
CAM_DRDY
I/O Configurable general purpose I/O pin /
Camera Interface on -PCS (4)
CMOS 2.8V
49 GPIO6
/ALARM
/PD[7]
I/O GP I/O pin or ALARM output pin /
Camera Interface on -PCS (4)
CMOS 2.8V
50 GPIO7
/BUZZER
/CAM_PWR_ON
I/O
GP I/O pin or BUZZER output pin /
Camera Interface on -PCS (4)
CMOS 2.8V
(1) For the exclusive use of the Technical Support Service
(2) An earphone with a 150 ohm impedance can be directly connected to EAR+ and EAR–
(3) On this pin a maximum of 47nF bypass capacitor is allowed.
(4) When activating the Easy camera these pins will not be available for other use
