1.15 Interface connectors on GM862-PCS
The Telit GM862-PCS module has two interface connectors and a SIM Card reader:
1) SO601: Antenna connector (see 1.7.1, Antenna connector)
2) SO301: Interface connector
3) SO402: SIM Card Reader
The GM862-PCS transceiver module interface connector SO301 is a CSTP 50 pin vertical SMD
Molex 52991–0508 (male). Its pin-out (down view) is:
49 50
1 2
Connector Position
and PIN-Out order
Antenna connector
position(on the
vertical side)
SIM CARD reader
position (on the
vertical side)
