2.7.1.9 #SGPO –Set General Purpose Output
#SGPO – set general purpose output
Execute command
Read command
AT#SGPO? Reports the #SGPO command setting, hence the opposite status of the
open collector pin in the format: #SGPO: <stat>.
Write command
AT#SGPO = <stat>
Sets the value of the general purpose output pin GPIO2 according to
<stat> parameter
Parameter:
<stat>
0 - output pin cleared to 0 (LOW)
1 - output pin set to 1 (HIGH)
Note: The GPIO2 is an OPEN COLLECTOR output, the command
sets the transistor base level, hence the open collector output is
negated:
AT#SGPO= 0 sets the open collector output HIGH
AT#SGPO= 1 sets the open collector output LOW
A pull up resistor is required on pin GPIO2.
Test command
AT#SGPO=?
Reports the supported range of values of the command parameter
<stat>.
Example
Reference Telit GM862-PCS AT Command Specification
