Telit GM862 PCS

Tri Band GPRS Data Terminal System

TECHNICAL

MANUAL

Code: 1vv0300638

Rev. 2

Oct. 23, 2003

Summary of content (195 pages)

PAGE 1
Telit GM862 PCS Tri Band GPRS Data Terminal System TECHNICAL MANUAL Code: 1vv0300638 Rev. 2 Oct.
PAGE 2
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System REVISION INDEX REV MOD.
PAGE 3
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System INDEX Part1 CAP TITLE REV 1 INTRODUCTION 2 2 MECHANICAL VIEW 0 3 TECHNICAL SPECIFICATIONS 1
PAGE 4
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 1 Rev. 2 INTRODUCTION The Telit GM862 PCS is a Tri Band transceiver with integrated Data Terminal Adapter functions that emulates a traditional modem allowing the compatibility in GSM/DCS/ PCS environment with many data communication software. The design and development of the Telit GM862 PCS Tri Band cellular data terminal system is in line with the following documents: 3GPP TS 51.010–1 v. 4.4.
PAGE 5
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev. 2 1.1 Delta HW between GM862–PCS HW rev.1 and GM862–PCS HW rev.2 The changes that determines the difference between the GM862–PCS HW rev.1 and the GM862–PCS HW rev.2 are the following: On the GM862–PCS HW rev.2 the following components are added/changed: Added: R103 47KOhm 0402 between AXE and Vcore. See CP030027 for further details. Changed: R327 changed value from 220R 5% 0402 to 820R 5% 0402 See CP030041 for further details.
PAGE 6
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2 MECHANICAL VIEW 2.
PAGE 7
Il presente disegno a termini di legge non deve essere utilizzato per la costruzione del particolare ne’ riprodotto o reso pubblico senza il nostro permesso scritto. MODIFICA DATA Valido da: Scala: DIS Lucà 1 Toll.gen. Sostituisce il N. Data 0260 Foglio 1:1 Verif. Progetto Materiale: 03.07.2003 Annotazioni: N.
PAGE 8
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 3 Rev. 1 TECHNICAL SPECIFICATIONS The scope of this document is to summarize the technical characteristics of the Telit GM862 PCS Data Terminal System.
PAGE 9
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 Contents 1 GENERAL PRODUCT DESCRIPTION.................................................................................7 1.1 Dimensions .............................................................................................................................................................................7 1.2 Weight..............................................................................................................
PAGE 10
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 1.16 Mounting the GM862-PCS on your Board................................................................................................................. 25 1.16.1 Antenna Coaxial cable fixing...................................................................................................................................25 1.16.2 Precautions...........................................................................................
PAGE 11
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.3.3 2.4.3.4 2.4.3.5 2.4.3.6 2.4.3.7 2.4.3.8 2.4.3.9 2.4.4 2.4.4.1 2.4.4.2 2.4.5 2.4.5.1 2.4.5.2 2.4.6 2.4.6.1 2.4.6.2 2.4.7 2.4.7.1 2.4.7.2 2.4.7.3 2.4.7.4 2.4.7.5 2.4.7.6 2.4.7.7 2.4.7.8 2.4.7.9 2.4.7.10 2.4.7.11 2.4.7.12 Rev.1 P - set pulse dial....................................................................................................................................................59 A - answer.............................
PAGE 12
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.3.13 2.5.3.14 5.4.3.15 2.5.4 2.5.4.1 2.5.4.2 2.5.4.3 2.5.4.4 2.5.4.5 2.5.4.6 2.5.4.7 2.5.4.8 2.5.4.9 2.5.4.10 2.5.4.11 2.5.4.12 2.5.4.13 2.5.4.14 2.5.4.15 2.5.4.16 2.5.4.17 2.5.5 2.5.5.1 2.5.5.2 2.5.6 2.5.6.1 2.5.7 2.5.7.1 2.5.7.2 2.5.7.3 2.5.7.4 3.3.7.1 2.5.7.5 3.3.7.2 3.3.7.3 2.5.8 2.5.8.1 Rev.1 +CLCC - list current calls ...............................................................................................................
PAGE 13
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.6.4.2 2.6.4.3 2.6.4.4 Rev.1 +CMSS - send message from storage.............................................................................................................141 +CMGW - write message to memory ............................................................................................................142 +CMGD - delete message...................................................................................................
PAGE 14
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.9.4.2 2.9.4.3 2.9.4.4 2.9.4.5 2.9.4.6 2.9.4.7 2.9.4.8 2.9.4.9 2.9.4.10 Rev.1 #PASSW – Authentication Password control...............................................................................................173 #PKTSZ –Packet Size control..........................................................................................................................174 #DSTO – Data Sending Timeout control..................................
PAGE 15
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 1 General Product Description 1.1 Dimensions The Telit GM862-PCS module overall dimension are: • Lenght: 43.9 mm • Width: 43.9 mm • Thickness: 6.9 mm • Volume: ≅ 13 cm3 The layout of Telit GM862-PCS module is shown in the following figure: Page 7 of 187 Rev.
PAGE 16
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 1.2 Weight The Telit GM862-PCS module weight is 23 gr with shield and 16 gr without shield. 1.3 Environmental requirements The Telit GM862-PCS module is compliant with the applicable ETSI reference documentation GSM 05.05 Release1999 ETSI EN300910 V8.4.1 1.3.
PAGE 17
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System • Rev.1 12 ÷ 150Hz –3dB/oct 1.4 Operating Frequency The operating frequencies in GSM, DCS, PCS modes are conform to the GSM specifications. Mode Freq. TX (MHz) Freq. RX (MHz) Channels (ARFC) TX - RX offset E-GSM-900 890.0 - 914.8 880.2 - 889.8 DCS-1800 1710.2 - 1784.8 935.0 - 959.8 925.2 - 934.8 1805.2 - 1879.8 0 – 124 975 - 1023 512 – 885 45 MHz PCS-1900 1930.2 - 1989.8 512 - 810 80 MHz 1850.2 - 1909.
PAGE 18
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 1.
PAGE 19
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 connector is locatable at: Telegärtner - K. Gärtner GmbH Lerchenstrasse 35, D-71144 Steinenbronn Phone: (+49) 71 57 125 100 NOTE: be very careful when connecting the Telit GM862-PCS module RF connector. The Telit GM862-PCS module RF connector can be damaged if not connected with the proper antenna RF connector. The minimum number of insertion cycles are recommended.
PAGE 20
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 1.8 Supply voltage The external power supply must be connected to VBATT signal (see paragraph 1.15,Interface connectors on GM862-PCS) and must fulfil the following requirements: • Nominal operating voltage 3.8 V • Operating voltage range 3.4 V - 4.2 V 1.
PAGE 21
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 1.11 Rev.1 User Interface The user interface is managed by AT commands specified on the GSM 07.07 and 07.05 specification and listed in the chapter 2, AT Command. 1.11.1 Speech Coding The Telit GM862-PCS vocoder supports the following rates: • Half Rate. • Full rate, • Enhanced Full Rate 1.11.2 Sim Reader The Telit GM862-PCS support phase 2 GSM11.14 - SIM 3 volts ONLY.
PAGE 22
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 1.11.6 Rev.1 Local security management With lock of Subscriber Identity module (SIM), and security code request at power–up. 1.11.7 Call control Call cost control function. 1.11.8 Phonebook Function available to store the telephone numbers in SIM memory. Capability depends on SIM version/memory 1.11.9 Characters management Availability of lowercase, uppercase and IRA characters.
PAGE 23
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 1.11.13 Automatic answer (Voice, Data or FAX) After n (depends of settings) rings automatically answers with beep (see S0 param). 1.11.
PAGE 24
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 Group high Group low 1209 Hz 1336 Hz 1477 Hz 697 Hz 1 2 3 770 Hz 852 Hz 4 7 5 8 6 9 941 Hz * 0 # 1.11.17 Buzzer output The General Purpose I/O pin GPIO7 can be configured to output the BUZZER output signal, with only an external Mosfet/transistor and a diode a Buzzer can be directly driven. The ringing tone and the other signaling tones can be redirected to this Buzzer output with a specific AT command. 1.
PAGE 25
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 Operating Range - Interface levels (2.8V CMOS) Level Min Max Input high level 2.1V 3.3V Input low level Output high level 0V 2.2V 0.5V 3.0V Output low level 0V 0.35V For 2,0V signals: Operating Range - Interface levels (2.0V CMOS) 1.13.1 Level Input high level Min 1.6V Max 3.3V Input low level 0V 0.4V Output high level 1,65V 2.2V Output low level 0V 0.
PAGE 26
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 Reset Signal Operating levels: Signal Min Max RESET Input high 2.2V* 3.3V RESET Input low 0V 0.2V * this signal is internally pulled up so the pin can be left floating if not used. If unused, this signal may be left unconnected. If used, then it must always be connected with an open collector transistor, to permit to the internal circuitry the power on reset and undervoltage lockout functions.
PAGE 27
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 1.14 Rev.1 Audio levels specifications The audio of the Telit GM862-PCS, module is organised into two main paths: - internal path (called also MT) - external path (called also HF) These two paths are meant respectively for handset and headset/handsfree use.
PAGE 28
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 1.15 Rev.1 Interface connectors on GM862-PCS The Telit GM862-PCS module has two interface connectors and a SIM Card reader: 1) SO601: Antenna connector (see 1.7.1, Antenna connector) 2) SO301: Interface connector 3) SO402: SIM Card Reader The GM862-PCS transceiver module interface connector SO301 is a CSTP 50 pin vertical SMD Molex 52991–0508 (male).
PAGE 29
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 30
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 31
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 23 RESET I Reset input 24 SIMRST O External SIM signal – Reset 25 MON1_CAM I/O Camera Interface on –PCS (4) CMOS 2.8V 26 SIMCLK O 3V ONLY 27 CCIN I/O External SIM signal – Presence (active low) 28 GPIO2 O General purpose output (Open Collector) / Camera Interface on –PCS (4) Open Collector 29 C106/CTS O Output for Clear to send signal (CTS) to DTE CMOS 2.
PAGE 32
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 48 GPIO5 CAM_DRDY I/O Configurable general purpose I/O pin / Camera Interface on -PCS (4) CMOS 2.8V 49 GPIO6 /ALARM /PD[7] I/O GP I/O pin or ALARM output pin / Camera Interface on -PCS (4) CMOS 2.8V 50 GPIO7 /BUZZER /CAM_PWR_ON I/O GP I/O pin or BUZZER output pin / Camera Interface on -PCS (4) CMOS 2.
PAGE 33
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 1.16 Rev.1 Mounting the GM862-PCS on your Board In order to electrically connect your board to the Telit GM862-PCS module, use a CSTP 2x25 pin vertical SMD SCH–SCH Molex 53748 - 0504 (female, low profile) as a counterpart to the CSTP 50 pin vertical SMD Molex 52991–0508 (male) of your Telit GM862-PCS module.
PAGE 34
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 - Angle connector fixing example 2 - NOTE: in the examples the cable is always bent, this is not a constrain. If the installation does not require it, then the cable can be kept straight, ensuring that the fixing is without sliding. 1.16.2 Precautions - The plug should be inserted in the connector only after the installation of the Telit GM862-PCS module in the board.
PAGE 35
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2 AT Command The Telit GM862-PCS module can be driven via the serial interface using the standard AT commands 1 . The Telit GM862-PCS module is compliant with: 1. Hayes standard AT command set, in order to maintain the compatibility with existing SW programs. 2. ETSI GSM 07.07 specific AT command and PCS specific commands. 3. ETSI GSM 07.05 specific AT commands for SMS (Short Message Service) and CBS (Cell Broadcast Service) 4.
PAGE 36
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.2 AT Command Syntax GSM commands use syntax rules of extended commands. Every extended command has a test command (trailing =?) to test the existence of the command and to give information about the type of its subparameters. There are two types of extended command: - Parameter type commands which also have a read command (trailing ?) to check the current values of subparameters.
PAGE 37
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.2.
PAGE 38
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 In the table below are listed all the commands whose timeout differs from the default 100 ms and their effective timeout is reported: Command +CBST Timeout (Seconds) 0.2 +CR 0.2 +CRC 0.2 +CRLP +CSCS 0.2 0.
PAGE 39
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System +CLVL 5 +CMUT 5 +CACM +CAMM 20 20 +CPUC 20 +CMEE 5 +VTS 20 +GMI 5 +GMM 5 +GMR 5 +GSN I3 20 5 I4 5 I5 5 +CSMS 5 +CPMS 5 +CMGF 5 +CSCA +CSMP 20 5 +CSDH 5 +CSAS 5 +CRES 5 +CNMI 5 +CMGS 180 / 5 for prompt">" +CMSS +CMGW 180 5 / 5 for prompt">" +CMGD 5 +CMGR 5 +CMGL 5 #CAP 10 #SRS 10 #SRP 10 #STM #PCT 10 10 #SHDN 10 #QTEMP 10 #SGPO 10 #GGPI 10 Page 31 of 187 Rev.
PAGE 40
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System #MONI 10 +CGACT 180 +CGATT +CGDATA 180 20 +CGDCONT 20 +CGPADDR 20 +CGQMIN 20 +CGQREQ 20 Rev.1 2.2.4 Command issuing timing The chain Command -> Response shall always be respected and a new command must not be issued before the GM862-PCS has terminated all the sending of its response result code (whatever it may be).
PAGE 41
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.3 Command Availability Table The available command, depending on the module are evidenced in the following table: GM862-PCS PRODUCT GM862-GPRS GM862-GSM &F • • • Z • • • +FCLASS • • • &Y • • • &W • • • &Z • • • &N • • • +GMI • • • +GMM • • • +GMR • • • +GCAP • • • +GSN • • • &V • • • &V0 • • • &V1 • • • &V2 • • • \V • • • %L • • • %Q • • • E • • • Q
PAGE 42
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +IPR • • • +IFC • • • +ILRR • • • +ICF • • • D • • • T • • • P • • • A • • • H • • • O • • • &G • • • &P • • • +MS • • • %E • • • +DS • • • +DR • • • \B • • • \K • • • S0 • • • S1 • • • S2 • • • S3 • • • S4 • • • S5 • • • S7 • • • S10 • • • S12 • • • S25 • • • S30 • • • S38 • • • +CGMI • • • +CGMM • • • +CG
PAGE 43
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 44
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +CRSL • • • +CLVL • • • +CMUT • • • +CACM • • • +CAMM • • • +CPUC • • • +CMEE • • • +VTS • • • +CGACT • • +CGATT • • +CGDATA • • +CGDCONT • • +CGPADDR • • +CGREG • • +CGQMIN • • +CGQREQ • • +CBC • ETSI GSM 07.
PAGE 45
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 46
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 47
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4 Hayes Compliant AT Commands 2.4.1 Generic Modem Control 2.4.1.1 &F - restore factory configuration &F – restore factory configuration Execute command AT&F Calls the factory configuration, resetting the default profile. Read command Write command Test command Example Reference V25ter. SW release Version A 2.4.1.
PAGE 48
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.1.3 +FCLASS - select active service class +FCLASS - select active service class Execute command Read command AT+FCLASS? Write command AT+FCLASS= Returns the current configuration value of the parameter . Set the GM862-PCS in specified connection mode (data, fax, voice), hence all the calls done after, will be data or voice.
PAGE 49
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.1.5 &W - store current configuration &W – store current configuration Execute command AT&W Stores on profile n the complete configuration of the device. Parameter: = 0…1 - profile Read command Write command Test command Example Reference SW release Version A 2.4.1.
PAGE 50
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.1.7 &N - display internal phonebook stored numbers &N – display internal phonebook stored numbers Execute command AT&N Returns the telephone number stored in the internal memory at the record number . Parameter: - phonebook record Note: if parameter is omitted then all the internal records are shown. Read command Write command Test command Example Reference SW release Version A 2.4.1.
PAGE 51
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.1.10 Rev.1 +GMR - request revision identification +GMR – request revision identification Execute command AT+GMR Returns the software revision identification. Read command Write command Test command Example Reference SW release 2.4.1.11 V.25ter Version A +GCAP - request capabilities list +GCAP – request capabilities list Execute command AT+GCAP Returns the equipment supported command set list.
PAGE 52
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.1.13 &V - display current configuration & profile &V – display current configuration & profile Execute command AT&V Returns all the configuration parameters settings.
PAGE 53
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.1.14 Rev.1 &V0 - display current configuration & profile &V0 – display current configuration & profile Execute command AT&V0 Returns all the configuration parameters settings. Note: this command is the same as &V, it is included only for backwards compatibility. Read command Write command Test command Example Reference SW release 2.4.1.
PAGE 54
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.1.16 &V2 - display last connection statistics &V2 – display last connection statistics Execute command AT&V2 Returns the last connection statistics & connection failure reason. Read command Write command Test command Example Reference SW release 2.4.1.17 Version A \V - single line connect message \V – Single line connect message Execute command AT\V Set single line connect message.
PAGE 55
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.1.18 %L - report line signal level %L – report line signal level Execute command AT%L Reports the line signal level. Note: Since on mobile phone there's no line connection, command is included only for compatibility and returns only OK. To check signal strength (level) use the +CSQ command. Read command Write command Test command Example Reference SW release 2.4.1.
PAGE 56
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.2 DTE - modem interface control 2.4.2.1 E - command echo E – command echo Execute command Read command Write command ATE Controls the command echo response of the device, enabling or disabling the echo. Parameter: = 0 - disables command echo, hence after this command the only characters received by DTE are the responses to commands sent to device.
PAGE 57
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.2.3 V- result code form V – result code form Execute command Read command Write command ATV Sets the result code format. Parameter: = 0 set the short format (terse) return codes are numbers 0-9. = 1 set the long form (verbose) return codes. Note: Line feed is not issued before a short format result code. Test command Example Reference V25ter SW release Version A 2.4.2.
PAGE 58
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.2.5 I - Request identifier and software checksum I – request identifier and software checksum Execute command Read command Write command ATI Returns the identifier and a software checksum. Parameter: = 0 numerical identifier.
PAGE 59
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.2.7 &D - data terminal ready (DTR) control &D – data terminal ready (DTR) control Execute command Read command Write command AT&D Controls the GM862-PCS behaviour to the RS232 DTR transitions. Parameter: = 0 DTR transitions are ignored. = 1 when the GM862-PCS is connected, the high to low transition of DTR pin sets the device in command mode, the current connection is NOT closed.
PAGE 60
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.2.9 &S - data set ready (DSR) control &S – data set ready (DSR) control Execute command Read command Write command AT&S Controls the RS232 DSR pin behaviour: n = 0 - always ON n = 1 - follows the GSM traffic channel indication.
PAGE 61
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.2.10 Rev.1 \R - ring (RI) control \R – ring (RI) control Execute command Read command Write command AT\R controls the RING output pin behaviour. Parameter: = 0 - RING on during ringing and further connection = 1 – RING on during ringing = 2 - RING follows the ring signal Note: to check the ring option status use the &V command. Test command Example Reference SW release 2.4.2.
PAGE 62
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.2.12 Rev.1 +IFC - DTE - DTA flow control +IFC – DTE-DTA flow control Execute command Read command AT+IFC? Returns active flow control settings.
PAGE 63
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.2.13 Rev.1 +ILRR - DTE - modem rate reporting +ILRR – DTE-modem rate reporting Execute command Read command AT+ILRR? Write command AT+ILRR = Returns active setting of port speed rate reporting information. Controls whether or not the +ILRR: information text is transmitted from the GM862-PCS to the DTE.
PAGE 64
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.2.14 Rev.1 +ICF - DTE - modem character format +ICF – DTE-modem character format Execute command Read command AT+ICF? Write command AT+ICF = [,] Test command AT+ICF=? Example Reference SW release Returns current value of the character format. Defines the asynchronous character format to be used when autobauding is disabled. Parameter: = 0..
PAGE 65
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.3 Call Control 2.4.3.1 D - dial D – dial Execute command ATD Starts a call to the phone number given as parameter. Parameter: - phone number to be dialled Note: The call is a data call or voice call depending on +FCLASS setting. If AT+FCLASS=8 command was issued before calling then the call will be done as a voice call, instead if AT+FCLASS=0 command was issued the call will be a data one.
PAGE 66
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 D – dial : a string which indicates the layer 2 protocol to be used (see +CGDATA command). For communications software that does not support arbitrary characters in the dial string, the following numeric equivalents shall be used: 1 - PPP Other values are reserved and will result in an ERROR response to the set command. : a digit string which specifies a particular PDP context definition (see +CGDCONT command).
PAGE 67
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.3.2 T - set tone dial T – set tone dial Execute command ATT It has no effect is included only for backward compatibility with landline modems. Read command Write command Test command Example Reference SW release V25ter. Version A 2.4.3.3 P - set pulse dial P – set pulse dial Execute command ATP It has no effect is included only for backward compatibility with landline modems.
PAGE 68
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.3.5 A/ - Last command automatic repetition A/ – last command automatic repetition Execute command A/ It is used to execute again the last received command. This command works only at fixed IPR. Note: This command has been substituted with AT#/ command. Refer to #/ command reference. Read command Write command Test command Example Reference SW release Version A 2.4.3.
PAGE 69
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.3.7 O - return to On Line Mode O – return to on line mode Execute command ATO It is used return to On-line mode from command mode. If there's no connection active returns ERROR. Note: After the issue of this command, if the device is in conversation, to send other commands to the device you must return to command mode by issuing the escape sequence or lowering DTR if &D1 option is active.
PAGE 70
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.3.9 &P - pulse dial make/break ratio &P – pulse dial make/break ratio Execute command AT&P It is has no effect is included only for backward compatibility with landline modems.. Read command Write command Test command Example Reference SW release Version A 2.4.4 Modulation control 2.4.4.
PAGE 71
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.4.2 %E - enable/disable line quality monitor and auto retrain or fallback / fallforward %E – enable/disable line quality monitor and auto retrain or fallback/fallforward Execute command AT%E It has no effect is included only for backward compatibility with landline modems.
PAGE 72
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.5 Compression control 2.4.5.1 +DS - set data compression +DS – set data compression Execute command Read command AT+DS? Write command AT+DS = Test command AT+DS=? Example Reference SW release Returns current value of the data compression parameter. Sets the V42 compression parameter.
PAGE 73
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.6Break control 2.4.6.1 \B - transmit break to remote \B – transmit break to remote Execute command Read command Write command AT\B It has no effect is included only for backward compatibility with landline modems Test command Example Reference SW release Version A 2.4.6.2 \K - break handling \K – break handling Execute command Read command Write command AT\K Response It has no effect is included only for backward compati
PAGE 74
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.7 S parameters 2.4.7.1 S0 - number of rings to auto answer S0 – number of rings to auto answer Execute command Read command ATS0? Write command ATS0 = Returns the current value of S0 parameter. Sets the number of rings required before device automatically answers an incoming call. Parameter: = 0-255 = 0 auto answer disabled Test command Example Reference V25ter SW release Version A 2.4.7.
PAGE 75
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.7.3 S2 - escape character S2 – escape character Execute command Read command Write command ATS2 = S2 holds the decimal value of the ASCII character used as escape character. This command sets this character equal to . Parameter: - escape character 0-255 Note: The escape sequence consists of three escape characters preceded by n ms of idle and followed by m ms of idle.
PAGE 76
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.7.5 S4 - line feed character S4 – line feed character Execute command Read command Write command ATS4 = Sets the character recognized as line feed character. Parameter: - line feed character 0-127 Note: Default 10 (Line Feed). The line feed character is output after carriage return character if verbose result codes are used ( V1 option used ). Test command Example Reference SW release V25ter Version A 2.4.7.
PAGE 77
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.7.7 S7 - wait time for carrier, silence or dial tone S7 – wait time for carrier, silence or dial tone Execute command Read command Write command ATS7 = S7 sets the length of time in seconds that the device will wait for carrier before hanging up the call. The timer is started when the device finishes dialing (originate), or 2 seconds after going offhook.
PAGE 78
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.4.7.9 S12 - escape prompt delay S12 – escape prompt delay Execute command Read command Write command ATS12 = Defines the guard time of silence before and after the escape sequence in order to accept it as a valid one. Parameter: - 20-255 fiftieth of seconds Note: default is 50 (1 second ) Test command Example Reference SW release 2.4.7.
PAGE 79
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.4.7.11 Rev.1 S30 - disconnect inactivity timer S30 –disconnect inactivity timer Execute command Read command Write command ATS30 = Defines the inactivity timeout timer value in minutes. The Device disconnects if no characters are exchanged for a time period of at least S30 minutes. Parameter: - 0-127 minutes = 0 - means inactivity timer disabled, hence no disconnect on inactivity feature is enabled.
PAGE 80
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5 ETSI GSM 07.07 AT Commands 2.5.1General 2.5.1.1 +CGMI - request manufacturer identification +CGMI – request manufacturer identification Execute command AT+CGMI Returns the device manufacturer identification code. Read command Write command Test command Example Reference SW release GSM 07.07 Version A 2.5.1.
PAGE 81
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.1.4 +CGSN - request product serial number identification +CGSN – request product serial number identification Execute command AT+CGSN Returns the product serial number, identified as the IMEI of the mobile. Read command Write command Test command Example Reference SW release GSM 07.07 Version A 2.5.1.
PAGE 82
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.1.6 +CIMI - request international mobile subscriber identity (IMSI) +CIMI – request international mobile subscriber identify (IMSI) Execute command AT+CIMI Returns the value of the Internal Mobile Subscriber Identity stored in the SIM. Note: A SIM card must be present in the SIM card housing, else the command returns ERROR. Read command Write command Test command Example Reference SW release GSM 07.
PAGE 83
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.2 Call control 2.5.2.1 +CBST - select bearer service type +CBST – select bearer service type Execute command Read command AT+CBST? Write command AT+CBST = , , Test command AT+CBST=? Example Reference SW release Returns current value of the parameters , and Selects the bearer service with data rate , and the connection element to be used when data calls are originated.
PAGE 84
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.2.2 +CRLP - radio link protocol +CRLP – radio link protocol Execute command Read command AT+CRLP? Write command AT+CRLP = , , , , Test command AT+CRLP=? Example Reference SW release Returns the current value of the RLP protocol parameters. Radio link protocol (RLP) parameters used when non-transparent data calls are originated may be altered with this command. Parameters: = 1...
PAGE 85
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.2.3 +CR - service reporting control +CR – service reporting control Execute command Read command AT+CR? Write command AT+CR = Returns current intermediate report setting Controls whether or not intermediate result code +CR: is returned from the TA to the TE.
PAGE 86
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.2.4 +CEER - extended error report +CEER – extended error report Execute command AT+CEER Reports a information text regarding some error condition that may occur: - the failure in the last unsuccessful call setup (originating or answering) - the last call release - the last unsuccessful GPRS attach or unsuccessful PDP context activation, - the last GPRS detach or PDP context deactivation.
PAGE 87
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.2.5 +CRC - cellular result codes +CRC – cellular result codes Execute command Read command AT+CRC? Write command AT+CRC = Test command AT+CRC=? Example Reference SW release Returns current value of the parameter . Controls whether or not the extended format of incoming call indication is used.
PAGE 88
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.3Network service handling 2.5.3.1 +CNUM - subscriber number +CNUM – subscriber number Execute command AT+CNUM Returns the subscriber number i.e. the phone number of the device that is stored in the SIM card.
PAGE 89
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.3.2 +CREG - network registration report +CREG – network registration report Execute command Read command Write command AT+CREG = Test command AT+CREG? Enables/disables network registration reports depending on the parameter mode.
PAGE 90
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System +CREG – network registration report Example AT OK at+creg? +CREG: 0,2 (the GM862-GPRS is in network searching state) OK at+creg? +CREG: 0,2 OK at+creg? +CREG: 0,2 OK at+creg? +CREG: 0,2 OK at+creg? +CREG: 0,1 (the GM862-GPRS is registered ) OK at+creg? +CREG: 0,1 Reference SW release OK GSM 07.07 Version A Page 82 of 187 Rev.
PAGE 91
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.3.3 +COPS - operator selection +COPS – operator selection Execute command Read command AT+COPS? Write command AT+COPS = [[,[, ]]] Test command AT+COPS=? Returns current value of , and Forces an attempt to register the GSM network operator, parameter defines whether the operator selection is done automatically or it is forced with parameter.
PAGE 92
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.3.4 +CLCK - facility lock/ unlock +CLCK – facility lock/unlock Execute command AT+CLCK = , [, [,]] Read command AT+CLCK=,2 It is used to lock or unlock a ME o a network facility.
PAGE 93
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +CLCK – facility lock/unlock Write command Test command AT+CLCK=? Example Reference SW release Reports all the facility supported by the device. GSM 07.07 Version A 2.5.3.5 +CPWD - change facility password +CPWD – change facility password Execute command AT+CPWD = , Changes the password for the facility lock function of the facility fac.
PAGE 94
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.3.
PAGE 95
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.3.
PAGE 96
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.3.8 +CCFC - call forwarding number and conditions +CCFC – call forwarding number and condition Execute command AT+CCFC = , [,[,[,][,,,] ]] Controls the call forwarding supplementary service. Registration, erasure, activation, deactivation, and status query are supported.
PAGE 97
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +CCFC – call forwarding number and condition Read command AT+CCFC = Queries the network for forwarding service settings on a specific ,2,[number>[, reason. The result is in the form: [,dopo +CCFC:,[,[,[,dopo s]]] s]]] where: = 0 - service not active = 1 - service active (calls will be forwarded) : - 1...
PAGE 98
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.3.9 +CCWA - call waiting +CCWA – call waiting Execute command AT+CCWA = [[,[,]]] Controls the call waiting indication supplementary service. Activation, deactivation, and status query are supported.
PAGE 99
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +CCWA – call waiting AT+CCWA=? Example Reports the supported values for the parameter . Reference SW release GSM 07.07 Version A 2.5.3.10 +CHLD - call holding services +CHLD – call holding services Execute command AT+CHLD = Controls the network call hold service.
PAGE 100
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.3.11 Rev.1 +CUSD - unstructured supplementary service data +CUSD – unstructured supplementary service data Execute command AT+CUSD = ,[] Enables /disables the unstructured service data reporting. Parameters: : is used to disable/enable the presentation of an unsolicited result code: +CUSD: [,,] to the TE.
PAGE 101
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System +CUSD – unstructured supplementary service data Read command AT+CUSD? Write command Test command AT+CUSD=? Reports the current value of the parameter Reports the supported values for the parameter : = 0 - result code presentation in the TA disabled = 1 - result code presentation in the TA enabled Example Reference GSM 07.07 SW release Version A Page 93 of 187 Rev.
PAGE 102
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.3.12 Rev.1 +CAOC - advice of charge +CAOC – advice of charge Execute command AT+CAOC = Controls the advise of charge service; the command also includes the possibility to enable an unsolicited event reporting of the CCM information. If unsolicited reporting is enabled DTE sends the result code +CCCM: when the CCM value changes, but not more than every 10 seconds.
PAGE 103
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.3.13 Rev.
PAGE 104
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.3.14 Rev.
PAGE 105
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 5.4.3.15 Rev.
PAGE 106
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4 Mobile Equipment control 2.5.4.
PAGE 107
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4.2 +CFUN Set phone functionality (Power Saving Management) +CFUN – power saving management Execute command Read command AT+CFUN? Write command AT+CFUN= reports the power saving status in the form: +CFUN: where - power saving status 1 - power saving disabled 5 - power saving enabled Note: The phone functionality remains always FULL. Enables/disables the power saving function.
PAGE 108
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4.
PAGE 109
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +CPIN – enter PIN Example Reference SW release AT+CMEE=1 OK AT+CPIN? +CME ERROR: 10 (error because you have to insert the SIM) AT+CPIN? +CPIN: READY (this response is after you have inserted the SIM) OK GSM 07.
PAGE 110
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4.4 +CSQ- signal quality +CSQ – signal quality Execute command AT+CSQ Reports received signal quality indicators in the form +CSQ:, where - received signal strength indication 0 - 113 dBm or less 1 - 111 dBm 2...30 - 109dBm ... -53 dBm / 2 dBm per step 31 - 51 dBm or greater 99 - not known or not detectable - bit error rate % 0 - less than 0.2 % 1 - 0.2% a 0.4% 2 - 0.4% a 0.8% 3 - 0.8% a 1.6% 4 - 1.
PAGE 111
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4.5 +CPBS - select phonebook memory storage +CPBS – select phonebook memory storage Execute command Read command Write command AT+CPBS = Selects phonebook memory storage , which will be used by other phonebook commands.
PAGE 112
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4.6 +CPBR - read phonebook entries +CPBR – read phonebook entries Execute command Read command Write command AT+CPBR = [,] Test command AT+CPBR=? Example Reference SW release returns phonebook entries in locations number from to from the current phonebook memory storage selected with +CPBS. If is omitted, only location is returned.
PAGE 113
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4.7 +CPBF - find phonebook entries +CPBF – find phonebook entries Execute command Read command Write command AT+CPBF = Test command AT+CPBF=? Issues a search for the phonebook records that have the text sub-string at the start of the name field and returns a report in the form +CPBF: ,,, where index, number, type and name have the same meaning than in the command +CPBR report.
PAGE 114
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4.
PAGE 115
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.4.
PAGE 116
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.4.10 Rev.1 +CALA - Alarm Management +CALA – Alarm Management Execute command Read command AT+CALA? Write command AT+CALA = [ [,[,[,]]]] Reports the current alarm time stored in the internal Real Time Clock, if present, in the format: +CALA: ,,[,] Stores in the internal Real Time Clock the current alarm time and settings defined by the parameters , ,,.
PAGE 117
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 was off, otherwise it remains fully operative. In both cases the GM862-PCS brings the pin GPIO6 high, provided its has been set to alarm output, and keeps it in this state until a #WAKE or #SHDN command is received or a 90s timeout occurs. If the device is in "alarm mode" and it does not receive the #WAKE command within 90s then it shuts down. 5 - the GM862-PCS will make both the actions as for type=2 and type=3.
PAGE 118
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.4.11 Rev.1 +CALM - alert sound mode +CALM – alert sound mode Execute command Read command Write command AT+CALM = It is used to select the general alert sound mode of the device. Parameter: = 0 - normal mode = 1 - silent mode (no sound will be generated by the device) Note: if silent mode (1) is selected then incoming calls will not produce alerting sounds but only the message RING or +CRING.
PAGE 119
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.4.13 Rev.1 +CLVL - loudspeaker volume level +CLVL – loudspeaker volume level Execute command Read command AT+CLVL? Reports the current setting of the loudspeaker volume in the format: +CLVL: Write command AT+CLVL = It used to select the volume of the internal loudspeaker audio output of the device. Parameter: - loudspeaker volume varies between 0 (min) and 10 (max).
PAGE 120
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.4.15 Rev.1 +CACM - accumulated call meter +CACM – accumulated call meter Execute command Read command AT+CACM? Write command AT+CACM = Reports the current value of the SIM ACM in the format +CACM: Note: the value is in units whose price and currency is defined with command +CPUC Resets the SIM Accumulated Call Meter (ACM). Internal memory CCM remains unchanged.
PAGE 121
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.4.17 Rev.1 +CPUC - price per unit and currency table +CPUC – price per unit and currency table Execute command Read command AT+CPUC? Reports the current values of and parameters in the format: +CACM : , Write command AT+CPUC = , , Sets the values of Advice of Charge related price per unit and currency table in SIM.
PAGE 122
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.5 Mobile equipment errors 2.5.5.1 +CMEE - report mobile equipment error +CMEE – report mobile equipment error Execute command Read command Write command AT+CMEE = Enables/disables the report of result code. +CME ERROR: as an indication of an error relating to the +Cxxx commands issued. When enabled, device related errors cause the +CME ERROR: final result code instead of the default ERROR final result code.
PAGE 123
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.5.2 +CME ERROR: - ME error result code This is NOT a command, it is the error response to +Cxxx GSM 07.07 commands. Syntax: AT+CME ERROR: Parameter: - error code can be either numeric or verbose.
PAGE 124
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.5.6 Voice Control (TIA IS-101) 2.5.6.1 +VTS: - DTMF tones transmission +VTS – DTMF tones transmission Execute command Read command Write command AT+VTS = Allows the transmission of DTMF tones Parameter: - a single ASCII character in the set 0-9, #,*,A-D Note: this commands operates in voice mode only Test command AT+VTS=? Returns +VTS(),(),() Example Reference SW release GSM 07.
PAGE 125
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.7 Commands For GPRS 2.5.7.1 +CGACT - PDP context activate or deactivate + CGACT – PDP context activate or deactivate Execute command Read command AT+CGACT? Returns the current activation states for all the defined PDP contexts.
PAGE 126
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.7.2 +CGATT - GPRS attach or detach + CGATT – GPRS attach or detach Execute command AT+CGATT = Read command AT+CGATT? Write command Test command AT+CGATT=? Example The command is used to attach the terminal to, or detach the terminal from, the GPRS service depending on the parameter . Parameter: - indicates the state of GPRS attachment 0 - detached 1 - attached Returns the current GPRS service state.
PAGE 127
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.7.3 +CGDATA - Enter data state + CGDATA – Enter data state Execute command The command causes to perform whatever actions are necessary to AT+CGDATA = [ establish communication with the network using one or more GPRS PDP types.
PAGE 128
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.7.
PAGE 129
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 AT+CGDCONT=? +CGDCONT: (1-3),”IP”,,,(0-1),(0-1) OK AT+CGDCONT=1, ”IP”, ”uni.tim.it”, ”10.10.10.10”,0,0 OK Reference GSM 07.07 SW release Version A 3.3.7.
PAGE 130
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.7.5 +CGREG - GPRS network registration status + CGREG – GPRS network registration status Execute command Read command AT+CGREG? Write command AT+CGREG = Test command AT+CGREG=? Example Reference SW release Returns the status of result code presentation mode and the integer which shows whether the network has currently indicated the registration of the terminal in the format: +CGREG:,.
PAGE 131
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 3.3.7.
PAGE 132
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 3.3.7.
PAGE 133
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.5.8 Commands For Battery Charger 2.5.8.
PAGE 134
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6 ETSI GSM 07.05 AT Commands for SMS and CB services 2.6.1 General configuration 2.6.1.
PAGE 135
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.1.2 +CPMS - preferred message storage +CPMS – preferred message storage Execute command Read command AT+CPMS? Reports the message storage status in the format: +CPMS:,,,,,,,, where , and are the selected storage memories for reading, writing and storing respectively.
PAGE 136
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.1.3 +CMGF - message format +CMGF –message format Execute command Read command AT+CMGF? Write command AT+CMGF = Reports the current value of the parameter = 0. Selects the SMS format to be used in reading and writing messages. Parameter: = 0 - PDU as defined in GSM 3.40 and GSM 3.41 = 1 - text Test command AT+CMGF=? Reports the supported value of parameter.
PAGE 137
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.1.5 +CSDH – Show parameters in text mode +CSDH –show parameters in text mode Execute command Read command AT+CSDH? Report the current setting in the format: +CSDH: Write command AT+CSDH= Show the additional parameters of received or stored SMS when the text mode is used (+CMFG=1).
PAGE 138
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.1.7 +CRES – Restore text mode settings +CRES –restore text mode settings Execute command Read command Write command AT+CRES = Test command AT+CRES=? Example Reference SW release Restore any setting saved by +CSAS command for +CSCA and +CSMP commands in local non volatile memory (or in the SIM if it has a dedicated store for this purpose). Parameter: : 0…3 – number of profile from which to recall the setting.
PAGE 139
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.1.8 +CSCB – Select Cell Broadcast Message types +CSCB –select Cell Broadcast Message types Execute command Read command AT+CSCB? Reports the current value of the parameters , and in the format: +CSCB: ,, Write command AT+CSCB= Selects the Cell Broadcast message types to be received by the device.
PAGE 140
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.6.1.9 +CMS ERROR - message service failure result code This is NOT a command, it is the error response to +Cxxx GSM 07.05 commands Syntax: AT+CMS ERROR: Parameter: - error code can be either numeric or verbose. values: Numeric Format Verbose Format 0...127 GSM 04.11 Annex E-2 values 128...255 GSM 03.40 sub clause 9.2.3.
PAGE 141
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.2 Message configuration 2.6.2.1 +CSCA - service center address +CSCA –service center address Execute command Read command AT+CSCA? Write command AT+CSCA=, Reports the current value of the default SCA in the format: +CSCA: , Note: if SCA is not present the device reports an error message. Sets the Service center Address to be used for mobile originated SMS transmissions.
PAGE 142
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.3 Message receiving and reading 2.6.3.1 +CNMI - new message indications to Terminal Equipment +CNMI – new message indications to terminal equipment Read command AT+CNMI? Returns the current parameter settings for +CNMI command in the form: AT+CNMI:,,,, Write command AT+CNMI=[, Selects the behavior of the device on how the receiving of new messages from the network is indicated to the DTE.
PAGE 143
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 144
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +CNMI – new message indications to terminal equipment Reference SW release GSM 07.05 Version A 2.6.3.2 +CMGL - list messages +CMGL – list messages Execute command Read command Write command AT+CMGL = Reports the list of all the messages stored into (see command +CPMS ) memory storage having the status equal to parameter.
PAGE 145
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 146
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.3.3 +CMGR - read message +CMGR – read message Execute command AT+CMGR = Reports the message with location value from preferred message storage (see +CPMS) in the format: (PDU Mode) +CMGR: , where - status of the message 0 - new message 1 - read message 2 - stored message not yet sent 3 - store message already sent - length of the PDU in bytes.
PAGE 147
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 148
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.4 Message sending and writing 2.6.4.1 +CMGS - send message +CMGS – send message Execute command (PDU Mode) AT+CMGS = (Text Mode) AT+CMGS= (PDU Mode) Sends to the network a SMS message input as a PDU. Parameter: = 8…176 - represents the length of the PDU to be sent in bytes. The device responds to the command with the prompt '>' and awaits for the number of bytes of PDU specified.
PAGE 149
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +CMGS – send message Write command Test command Example Reference SW release GSM 07.05 Version A 2.6.4.2 +CMSS - send message from storage +CMSS – send message from storage Execute command AT+CMSS = Sends to the network, the message which is already stored in the storage (see +CPMS) at the location .
PAGE 150
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.6.4.3 +CMGW - write message to memory +CMGW – write message to memory Execute command (PDU Mode) AT+CMGW = (Text Mode) AT+CMGW = [] (PDU Mode) Writes in the memory storage a new SMS message input as a PDU. Parameter: - represents the length of the PDU to be written in bytes. The device responds to the command with the prompt '>' and awaits for the number of bytes of PDU specified.
PAGE 151
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 +CMGW – write message to memory Read command Write command Test command Example Reference GSM 07.05 SW release Version A 2.6.4.4 +CMGD - delete message +CMGD – delete message Execute command AT+CMGD = [,] Deletes from memory the message/messages Note: if the location to be deleted is empty, an error message is reported.
PAGE 152
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.7 Custom AT Commands 2.7.1 General configuration 2.7.1.
PAGE 153
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.7.1.2 #SRS - Select ringer sound #SRS – select ringer sound Execute command AT#SRS = [,] Set the ringer sound. The parameters are: - ringing tone 0 - current ringing tone 1 .. 12 - ringing tone number ringing tone playing timeout in seconds. 0 - no ringing tone playing, only tone setting 1 .. 60 - tone playing for seconds and successive tone setting.
PAGE 154
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.7.1.3 #SRP –Select Ringer Path #SRP – select ringer path Execute command AT#SRP= Selects the audio path towards whom sending ringer sounds and all signaling tones.
PAGE 155
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.7.1.
PAGE 156
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.7.1.6 #SHDN – Software Shut Down #SHDN – software shutdown Execute command AT#SHDN After the issuing of this command device detaches from the network and shuts down. Before definitive shut down an OK response is returned. Note: after the issuing of this command any previous activity is terminated and the device will not respond to any further command. To turn it on again Hardware pin ON/OFF must be tied low.
PAGE 157
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.7.1.7 #WAKE – Wake from Alarm mode #WAKE – Wake from Alarm Mode Execute command AT#WAKE=0 Read command AT#WAKE? After the issuing of this command device exits the "Alarm mode" and enters the normal operating mode. After entering in normal operating mode an OK response is returned. With the execution of is command all Alarm activity (for example alarm tone playing ) is immediately terminated.
PAGE 158
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.7.1.8 #QTEMP –Query Temperature overflow #QTEMP – query temperature overflow Execute command Read command AT#QTEMP? Write command AT#QTEMP = Queries the internal temperature sensor of the device for over temperature.
PAGE 159
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.7.1.9 #SGPO –Set General Purpose Output #SGPO – set general purpose output Execute command Read command AT#SGPO? Write command AT#SGPO = Test command AT#SGPO=? Reports the #SGPO command setting, hence the opposite status of the open collector pin in the format: #SGPO: .
PAGE 160
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.10 Rev.
PAGE 161
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.11 Rev.
PAGE 162
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.
PAGE 163
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.12 Rev.
PAGE 164
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.13 Rev.
PAGE 165
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.14 Rev.1 #ACAL – Set Automatic Call #ACAL – set automatic call Execute command Read command AT#ACAL? Write command AT#ACAL = Returns the current status in the format: #ACAL: Enable the automatic call. Parameter: = 0 – disable = 1 – enable If enabled, the transition OFF/ON of DTR causes an automatic data call to the number stored in position number 1 of the phone book. The &D command must be set to 2.
PAGE 166
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.15 Rev.1 #SMOV – SMS Overflow #SMOV – SMS overflow Execute command Read command AT#SMOV? Write command AT#SMOV= Return the current status in the format: #SMOV: . Enable the signalling of SMS overflow Parameter: = 0 - disable = 1 - enable If enable, when the maximum storage capacity has came, the #USMO: network initiated notification is send.
PAGE 167
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.17 #HFMICG – Handsfree Microphone Gain #HFMICG – handsfree microphone gain Execute command Read command AT#HFMICG? Write command AT#HFMICG = Test command AT#HFMICG=? Example Reference SW release 2.7.1.
PAGE 168
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.19 Rev.1 #SHFSD – Set Handsfree side tone #SHFSD – set handsfree side tone Execute command Read command AT#SHFSD? Return the current status in the format: #SHFSD: Write command AT#SHFSD = Set the sidetone on handsfree audio output. Parameter : 0 - disabled - headset mode (default) 1 - enabled - handsfree mode 2…255 reserved Note: This setting returns to default after power off.
PAGE 169
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.7.1.21 #BND – Select Band (DCS 1800 or PCS 1900) #BND – Select Band (DCS1800 or PCS1900) Execute command Read command AT#BND? Write command AT#BND = Return the current band selected in the format: #BND: Set the band parameter to the Band value. Parameter : 0 - DCS 1800MHz 1 - PCS 1900MHz Note: This setting is maintained even after power off.
PAGE 170
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.8 FAX Class 1 Commands 2.8.1 General configuration 2.8.1.1 +FCLASS - select active service class +FCLASS - select active service class Execute command Read command AT+FCLASS? Write command AT+FCLASS= Returns the current configuration value of the parameter . Set the GM862-PCS in specified connection mode (data, fax, voice), hence all the calls done after, will be data or voice.
PAGE 171
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.8.1.2 +FMI – Report manufacturer ID +FMI – Report manufacturer ID Execute command Read command AT+FMI? Reports the manufacturer ID Write command Test command Example AT+FMI? Telit Mobile Terminals OK Reference SW release ITU T.31 and TIA/EIA-578-A specifications Version A 2.8.1.
PAGE 172
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.8.1.4 +FMR – Report revision ID +FMR – Report revision ID Execute command Read command AT+FMR? Reports the software revision ID Write command Test command Example AT+FMR? 1.01.000 CS988 OK Reference SW release ITU T.31 and TIA/EIA-578-A specifications Version A 2.8.2 Transmission/Reception control 2.8.2.
PAGE 173
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.8.2.2 +FRS – Wait for receive silence +FRS – Wait for receive silence Execute command Read command Write command AT+FRS= this command causes the modem to listen and report an OK result code when silence has been detected for the specified period of time. This command when the required silence period is detected or when the DTE sends another character other than XON or XOFF.
PAGE 174
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.8.2.4 +FRM – Receive data modulation +FRM – Receive data modulation Execute command Read command Write command AT+FRM= this command causes the module to receive facsimile data using the modulation defined by the parameter . parameter : carrier modulation 24 - V27ter/2400 bps 48 - V27ter/4800 bps 72 - V29/7200 bps 96 - V29/9600 bps Test command AT+FRM=? Returns all supported values of the parameters .
PAGE 175
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.8.2.6 +FRH – Receive data with HDLC framing +FRH – Receive data data with HDLC framing Execute command Read command Write command AT+FRH= this command causes the module to receive facsimile data using HDLC protocol and the modulation defined by the parameter . parameter : carrier modulation 3 - V21/300 bps Test command AT+FRH=? Example Returns all supported values of the parameters .
PAGE 176
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.8.3.2 +FPR – Select serial port rate +FPR – Select serial port rate Execute command Read command Write command AT+FPR= Test command AT+FPR=? Example Reference SW release Selects the the serial port speed in both directions: from DTE to DTA and from DTA to DTE. When autobauding is selected, then the speed is detected automatically.
PAGE 177
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.9 Easy GPRS Extension 2.9.1 Overview The Easy GPRS feature applies only to the Telit GM862-PCS and allows a Telit GM862-PCS user to contact a device in internet and establish with it a raw data flow over the GPRS and Internet networks.
PAGE 178
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 All these steps are achieved through AT commands. As for common modem interface, two logical status are involved: command mode and data traffic mode. - In Command Mode (CM), some AT commands are provided to configure the Data Module Internet stack and to start up the data traffic.
PAGE 179
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System - Rev.1 GM862-PCS establishes a TCP/UDP (depending on the parameter request) connection with the given internet host Once the connection is up the module reports the code: CONNECT From this moment the data incoming in the serial port is packet and sent to the Internet host, while the data received from the host is serialised and flushed to the Terminal Equipment. 2.9.2.
PAGE 180
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.9.4 Easy GPRS custom AT command Definition 2.9.4.1 #USERID – Authentication User ID control #USERID – Authentication User ID control Execute command Read command AT#USERID? Write command AT#USERID="" Test command AT#USERID=? Example Reports the current value of the parameter . This command sets the user identification string to be used during the authentication step to be the string .
PAGE 181
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.9.4.2 #PASSW – Authentication Password control #PASSW – Authentication Password control Execute command Read command AT#PASSW=? Write command AT#PASSW="" Reports the maximum password length. This command sets the user password string to be used during the authentication step to be the string . Parameter: - authentication password - any string value up to max length reported in the Test command.
PAGE 182
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.9.4.3 #PKTSZ –Packet Size control #PKTSZ –Packet Size control Execute command Read command AT#PKTSZ? Write command AT#PKTSZ= Test command AT#PKTSZ=? Example Reference SW release Reports the current value of the parameter . This command sets the default packet size to be used by the TCP/UDP/IP stack for data sending.
PAGE 183
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.9.4.4 #DSTO – Data Sending Timeout control #DSTO –Data Sending Timeout control Execute command Read command AT#DSTO? Write command AT#DSTO= Test command AT#DSTO=? Example NOTE Reports the current value of the parameter .
PAGE 184
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.9.4.5 #SKTTO – Socket inactivity timeout control #SKTTO – Socket inactivity timeout control Execute command Read command AT#SKTTO? Write command AT#SKTTO= Test command AT#SKTTO=? Example Reference SW release Reports the current value of the parameter .
PAGE 185
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.9.4.6 #SKTSET – Socket definition control #SKTSET – Socket definition control Execute command Read command AT#SKTSET? Write command AT#SKTSET=, , "" Reports the current value of the parameters ,, . This command sets the socket parameters values.
PAGE 186
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.9.4.7 #SKTOP – Socket Open command #SKTOP – Socket Open Command Execute command AT#SKTOP Activates the context number 1, proceeds with the authentication with the user ID and password previously set with #USERID #PASSW commands, and opens a socket connection with the host specified in the #SKTSET command. Eventually before opening the socket connection it issues automatically a DNS query to solve the IP address of the host name.
PAGE 187
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 2.9.4.9 #SKTSAV – Socket Parameters Save Command #SKTSAV – Socket Parameters Save Command Execute command AT#SKTSAV Saves the actual Parameters of the Socket in the NVM of the device.
PAGE 188
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.9.4.10 Rev.1 #SKTRST – Socket Parameters Reset Command #SKTRST – Socket Parameters Reset Command Execute command AT#SKTRST Resets the actual Parameters of the Socket in the NVM of the device to the default ones.
PAGE 189
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.10 Easy Camera custom commands 2.10.1.1 #CAMON – Camera ON #CAMON – Camera ON Command Execute command Turns ON the Camera. AT#CAMON Read command Write command Test command Example AT#CAMON OK … camera is now powered up. Reference SW release Telit specifications Version D 2.10.1.2 #CAMOFF – Camera OFF #CAMOFF – Camera off Command Execute command Turns OFF the Camera.
PAGE 190
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.10.1.3 Rev.1 #TPHOTO – Camera Take Photo #TPHOTO – Camera Take Photo Command Execute command AT#TPHOTO Commands the CAMERA to take the photo and stores it in the GM862 memory. Read command Write command Test command NOTE The photo is kept in the GM862-PCS RAM memory, therefore after a power off it is lost. There's only 1 position for the photo, every photo will overwrite the previous.
PAGE 191
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.10.1.5 Rev.
PAGE 192
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System 2.10.1.6 Rev.
PAGE 193
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System Rev.1 3 Conformity Assessment The Telit GM862-PCS module is assessed to be conform to the R&TTE Directive as stand-alone product, so if you use them it will not be required any further test effort on the modules.
PAGE 194
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System List of acronyms ACM Accumulated Call Meter ASCII AT American Standard Code for Information Interchange Attention commands CB CBS CCM Cell Broadcast Cell Broadcasting Service Call Control Meter CLIP CLIR Calling Line Identification Presentation Calling Line Identification Restriction CMOS CR CSD Complementary Metal-Oxide Semiconductor Carriage Return Circuit Switched Data CTS DAI Clear To Send Digital Audio Interface DCD DCE DR
PAGE 195
TECHNICAL MANUAL Telit GM862 PCS Tri Band GPRS Data Terminal System LED Light Emitting Diode LF ME Linefeed Mobile Equipment MMI MO MS Man Machine Interface Mobile Originated Mobile Station MT OEM Mobile Terminated Other Equipment Manufacturer PB PDU PH Phone Book Protocol Data Unit Packet Handler PIN PLMN Personal Identity Number Public Land Mobile Network PUCT PUK RACH Price per Unit Currency Table PIN Unblocking Code Random Access Channel RLP RMS Radio Link Protocol Root Mean Square RTS
