Telink RCU TLSR8278ARC48D User Manual Features; Pin connection; User manual Brief： This is a user manual for Telink 8278 RCU.
Telink RCU TLSR8278ARC48 User Manual Published by Telink Semiconductor Bldg 3, 1500 Zuchongzhi Rd, Zhangjiang Hi-Tech Park, Shanghai, China © Telink Semiconductor All Right Reserved Legal Disclaimer This document is provided as-is. Telink Semiconductor reserves the right to make improvements without further notice to this document or any products herein. This document may contain technical inaccuracies or typographical errors.
Telink RCU TLSR8278ARC48 User Manual Table of contents 1 Product Introduction .............................................................................................. 3 1.1 General description.......................................................................................... 3 1.2 Key features ..................................................................................................... 3 2 Pin Connection Guide ...........................................................................
Telink RCU TLSR8278ARC48 User Manual 1 Product Introduction This is a user manual for Telink RCU TLSR8278ARC48D. 1.1 General description The TLSR8278ARC48D, which is based on Telink TLSR8278F1KET48 chip, provides a Bluetooth LE . The TLSR8278ARC48D integrates a power-balanced 32-bit MCU, BLE , 64kB SRAM, 1MB internal Flash, 14bit ADC , 6-channel PWM, flexible GPIO interfaces, and nearly all the peripherals needed for IoT (Internet of Things) and HID (Human Interface Devices) application development (e.g.
Telink RCU TLSR8278ARC48 User Manual connect the GND of TP4.
Telink RCU TLSR8278ARC48 User Manual When the remote control is used with a shell, it is directly powered by two dry batteries. As shown below.
Telink RCU TLSR8278ARC48 User Manual 2.2 Download firmware To download firmware into TLSR8278ARC48D, first make sure the TLSR8278ARC48D is supplied with power normally. That is, connect the power to the VDD of TP3, and connect the GND to TP4. See the next page picture shows. Then connect TP1 (SWS) of the TLSR8278ARC48D with SWM of a burning EVK. Meanwhile, connect the miniUSB interface of the burning EVK with PC USB.
Telink RCU TLSR8278ARC48 User Manual SWS 3V3 GND Figure 2 Connection chart to download firmware 7
Telink RCU TLSR8278ARC48 User Manual 2.3 Test RF signal To test RF signal of TLSR8278ARC48D, first make sure the TLSR8278ARC48D is supplied with power normally. That is, connect the power to the VDD of TP3, and connect the GND to TP4. Attach the semi-rigid cable welding steel to the PCBA GND. Then solder wire core to feed point. See the next page picture shows.
Telink RCU TLSR8278ARC48 User Manual Feed point GND 3V GND Figure 3 Connection chart to test RF signal 9
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
