Installation of

WC Gear

Introduction

This section shows you how to install WC Gear. This includes physical mounting and

wireless connections.

Note: Before installing WC Gear, read through the section on WC Gear Panels.

Topics

 Physical Mounting

 Wireless Connections

Physical Mounting

Wirecast Gear comes configured for table-top use with the included feet pre-attached.

The unique size and shape of Wirecast Gear is designed to occupy a minimum of space

while making connectors and cables easily accessible.

Also included with all Gear systems are two rack-mount "ears" and screws that allow the

system to fit into a standard 19-inch rack and take up 1.3 RU (Rack Units). This

configuration is useful for in-place racks and mobile flypacks where convenient and

safe transport of your live production system is required.

Note: The rack-mount configuration will require removal of rubber feet remove the

vent warning label on top of the unit, if desired. It is there to remind you to never block

the top of chassis air vents.

Wireless Connections

To make connections to your Wirecast Gear system, refer to WC Gear Panels for

connector functions and locations, and then follow these steps.
