WC Gear
Panels
Introduction
The following topics describe the Wirecast Gear front and rear panels.
Note: Please do not make any connections just yet. First, read the panel and connector
descriptions and then proceed to the Installation of WC Gear topic for steps to install
and connect to the unit.
Wirecast Gear is available in HDMI and SDI configurations. Both configurations share
the same front panel features, but each configuration has a unique rear panel. Wirecast
Gear 100 series models include 4-channel HDMI professional inputs, while Wirecast
Gear 200 series models are SDI-based and use BNC connectors.
Topics
Front Panel
Rear Panel
Rear Panel Differences
