User Manual

Introduction to WC Gear
Specifications
12
• NewBlueFX Titler Live Standard, Advance NDI, or Ultimate
– Model 110 uses NewBlueFX Titler Present
– Model 210 uses NewBlueFX Titler Sport
– Model 220 & 230 uses NewBlueFX Titler Complete
Hardware Specifications
• Intel Core i7-6700 8M Skylake Quad-Core 3.4 GHz
• Intel HD Graphics 530
• Memory - DDR4 Dual Channel Memory
• System Drive - M.2 SATA System Drive
• Storage Drive(s) - High speed SATA 6Gb/s SSD (single or dual, depending on model)
• Video Ingest - 4-channel professional camera inputs with HDMI or SDI models available
• Motherboard features
– Intel® USB 3.0 with USB Type-C™
– 802.11ac 867 Mbps dual band wireless (including antenna) + Bluetooth®
– 115dB SNR HD Audio with Built-in Rear Audio Amplifier
– Dual Intel® GbE LAN RJ45
– PS/2 Keyboard/Mouse Port
– USB 3.0 Ports - 4 rear/2 front
– Display outputs - DVI-D, dual HDMI
• Wireless Keyboard and Mouse combo
• Power Supply: AC input, auto-sensing, suitable for most countries worldwide
– Input Range: 90 ~ 264Vac (RMS), Full Range Input
– Frequency: 47 ~ 63Hz
– Input Current: Max 6A (RMS) @ 115Vac, 3A (RMS) @ 230Va
• Dimensions: 16.55 x 9.85 x 2.25 inches, 1.3U rackmount height (rear brackets avail-
able for transport cases).
Note: Wirecast Gear has no user-serviceable parts. Any repair or additional PCI card
installation must be performed by Telestream or an authorized Telestream service
technician.
