User manual

Part 3: Automation Control Variable Reference
app
app is the root of the XStreamDSO automation hierarchy; all other nodes are accessed from this point.
Nested within the app object are the principal XStreamDSO subsystems. Standard and optional
subsystems are arranged alphabetically.
Child Objects
Object Description
app.Acquisition
Subsystems related to the acquisition and digitization of signal: all
inputs, Timebase (Horizontal), and Trigger.
app.Cursors
Cursor (measure) subsystem.
app.CustomDSO
Custom DSO (XDEV) option. Standard on WavePro, WaveMaster, and
LabMaster oscilloscopes and equivalent DDA/SDA models.
app.Display
Display subsystem.
app.DriveAnalysis Disk Drive Analyzer option. Standard on DDA model oscilloscopes.
app.EyeDr Eye Doctor II option. Standard on SDA model oscilloscopes with SDAIII.
app.HardCopy
Hardcopy (Print) subsystem.
app.Help Online Help subsystem.
app.History
History Mode subsystem.
app.LabNotebook
LabNotebook subsystem.
app.Math
Math (Function) subsystem.
app.MotorDriveAnalysis Motor Drive Analyzer option. Standard on MDA800 oscilloscopes.
app.Measure
Measure (Parameter) subsystem.
app.Memory
Internal memory (storage) subsystem.
app.OMA Optical Modulation Analysis option. Standard on OMA systems.
app.PassFail
Pass/Fail testing subsystem.
app.Preferences
Application preferences subsystem.
app.ProbesCal
Probe calibration subsystem.
app.SaveRecall
Save Recall (File) subsystem.
app.SDA2 or app.SDA3 SDA II and SDA III options. Standard on SDA model oscilloscopes.
app.SpecAnalyzer
Spectrum Analyzer option. Standard on HDO6000, HDO8000, and
MDA800 oscilloscopes.
app.SystemControl
Mouse/pointer control subsystem.
app.TriggerScan
TriggerScan subsystem.
app.Utility
Utilities subsystem.
app.VirtualProbe Virtual Probe option. Standard on SDA model oscilloscopes with SDA III.
app.WaveScan
WaveScan subsystem.
3-3
