Note: You can only select Units from the list of values that appears following the Type selection.
Equations
CVARs app.Math.Fn.Equation, app.Math.Fn.EquationRemote, and
app.Measure.Pn.Equation are text Strings containing the summary of the math or measure operation.
They can be used to query the current settings, but not to set the function or parameter.
To set up a Math function, use the CVARs app.Math.Fn.Sourcen and app.Math.Fn.Operatorn, and any
objects in the app.Math.F1.OperatornSetup folders.
To set up a Parameter, use the CVARs app.Measure.Pn.Sourcen and
app.Measure.Pn.ParamEngine, plus any objects in the app.Measure.Pn.Operator subfolder.
Labels
The CVARs LabelsText and LabelsPosition (which appear in the hierarchy for any waveform object)
specify the text and position of custom labels placed on a waveform. LabelsText takes a single String
argument for which you can specify a comma-delimited list of values each representing a separate label:
app.Acquisition.C1.LabelsText = "Hello,World"
The above control creates two labels, "Hello" and "World." Note that later sending the same control with
only a single value will erase all but the first label in the list (which will remain at its current position),
changing it to the new text string.
LabelsPosition is also a String where each list value is a pipe-delimited pair specifying the horizontal and
vertical position of the corresponding label in the LabelsText string. Placing parentheses around the
vertical value in the pair turns on "Use Trace Vertical Position". The following control would position both
labels "Hello" and "World", placing "Hello" adjacent to the trace, and "World" at the vertical position specified:
app.Acquisition.C1.LabelsPosition = "0.000002|(0.02),0.000002|0.01"
Colors
Color type CVARs set/query the color of traces and other display objects, using a number in the range 0 to
FFFFFF in hexadecimal. The possible colors are made from any combination of the primary colors, which
are set in hexadecimal as Blue = &HFF0000, Green = &HFF00, Red = &HFF. For example:
app.Display.C1Color = "255,255,0"
The value may be entered in decimal or in hexadecimal, though hexadecimal is usually more convenient.
Note that if the intensity of a color is to be reduced or increased by a numerical factor, an AND operation
must be used afterwards, to prevent corruption of other primary colors.
File Names
CVARs of the Filename type generally do not require the full path to be given as part of the value, but in
most cases, the directory in which the files will be saved is set using a separate CVAR, which does require
the full path. Check the parent objects within the subsystem in XStreamBrowser to find the CVAR for
setting the file path.
