Part 2: Automation Programming Reference
Approach 3: Program Using ActiveDSO
As not all controllers can utilize the Windows DCOM architecture, there is another simplified method for
remote control of the XStreamDSO application: ActiveDSO, Teledyne LeCroy's proprietary Active-X
control. ActiveDSO can be used for much more than just remote control programs, but this exercise
shows how the same Automation commands used for remote control in Exercise 2 could be sent using
ActiveDSO, instead.
ActiveDSO also has the advantage of working with programming languages besides Visual Basic, such as
Python and Visual C++, making it easy to utilize as a remote control/waveform transfer subroutine within
other programs, or as part of a custom remote control interface. For more information, see the ActiveDSO
topic in the "Making the Remote Connection" section.
Preliminary Setup
1. Download ActiveDSO from teledynelecroy.com (see Resources) and install it on the PC.
2. Open XStreamBrowser and NotePad or another text editor on the PC.
3. Turn on the oscilloscope. For this exercise, we'll continue to use VBS and a LAN connection, so
confirm the oscilloscope is connected to LAN (or has a cross-over connection to your PC).
4. Go to Utilities > Utilities Setup > Remote and confirm the TCP/IP (VICP) setting.
5. Note the oscilloscope's IP address.
Program
Note: Characters in angle brackets are placeholders. Omit the brackets from your code.
Connect
In the text editor, instantiate the ActiveDSO control:
Set dso = CreateObject("LeCroy.ActiveDSOCtrl.1")
Then, invoke the MakeConnect method, in this case using the oscilloscope's IP address:
Call dso.MakeConnection("IP:<IP address>")
This method could have used USBTMC, GPIB, or any other supported connection type. You would want to
be sure to choose control from that same interface on the oscilloscope Remote dialog.
AutoSetup
Besides the instantiation method, the most obvious difference between using native VBS and using
ActiveDSO is in how commands are sent. With ActiveDSO, Automation controls are nested within the VBS
command. Write the line:
Call dso.WriteString("VBS 'app.AutoSetup'", 1)
The Boolean "1" is telling the XStreamDSO application to interpret the command immediately.
