MAUI Oscilloscopes Remote Control and Automation Manual
XStreamBrowser
The XStreamBrowser utility enables you to view, copy, and modify the COM object hierarchy of a
Windows-based MAUI™ oscilloscope from a remote PC. It is essential for writing Automation programs, as
it always shows all the Automation objects on the instrument at the exact current configuration—including
those objects belonging to software options. It can also be used as a remote control console, enabling you
to directly alter the configuration of Automation control variables.
XStreamBrowser is installed on all MAUI oscilloscopes for local browsing, but it may also be installed on
any PC for remote control. You must first allow a DCOM connection between the PC and oscilloscope,
then connect the XStreamBrowser to the device. The browser window is populated when the DCOM
connection is successful.
Note: WaveSurfer 3000 users should install the WaveStudio software instead of XStreamBrowser.
The COM object hierarchy of a connected device is shown in the WaveStudio Automation
Browser.
Caution: The version of XStreamBrowser available for download on our website is a 32-bit version
that will run on 64-bit machines. It is intended only for installation on remote PCs, not on
oscilloscopes. A 64-bit version of XStreamBrowser is already installed on 64-bit MAUI
oscilloscopes. Installing the 32-bit version over this will cause registry conflicts. Likewise, if you
have installed the 64-bit MAUI firmware on your PC, you already have a copy of the 64-bit
XStreamBrowser. If it was uninstalled, reinstall the MAUI firmware, rather than install the 32-bit
version of XStreamBrowser.
Connecting to a Local Device
To launch XStreamBrowser on the oscilloscope:
1. Choose File->Minimize to display the Windows desktop.
2. Double-click the XStreamBrowser icon.
3.
Select the connection icon.
Connecting to a Remote Device
1. Be sure the oscilloscope is configured to allow a DCOM connection from the PC.
2. Launch XStreamBrowser on the PC.
3.
Select the connection icon.
4. Enter the network IP Address of the oscilloscope, then click OK.
2-4
