MAUI Oscilloscopes Remote Control and Automation Manual
Resources
Teledyne LeCroy provides many free resources to help you receive the greatest value from your
instrument. Most of the software and documentation mentioned in this manual can be downloaded from
our website; links are provided to other sites where relevant. In addition, many manuals and code
examples for further reference are installed when you install our software.
Software
Download software from: teledynelecroy.com/support/softwaredownload.
Under Oscilloscope Downloads, click the link to Software Utilities and browse the list of tools.
Manuals
Download manuals, application notes, and lab briefs from: teledynelecroy.com/support/techlib.
Use the sidebar at the left of the page to select the document category, then browse the list of links.
Technical Support
Registered users can contact their local Teledyne LeCroy service center at the number listed on our
website.
You can also submit Technical Support requests via the website at:
teledynelecroy.com/support/techhelp
Select the oscilloscope model you are using and the category into which your question falls.
