MAUI Oscilloscopes Remote Control and Automation Manual
DD_SAM_THRESH, DST
Description
Sets the SAM threshold value for channel emulation.
Command Syntax
DD_SAM_THRESH <threshold>
<threshold>:= float (range depends on signal type)
Channel emulation error threshold is in units of Sequenced Amplitude Margin (SAM). The minimum
threshold is 0.0 channel emulation without reference and –1.0 for channel emulation with reference.
Maximum allowed thresholds are:
Signal Type Maximum SAM Threshold
PR
42.00
EPR
41.00
E2PR
41.11
Query Syntax
DD_SAM_THRESH?
Response Format
DD_SAM_THRESH <threshold>
Related Commands
DD_FIND_ERROR, DD_FIND_METHOD
6-188
