MAUI Oscilloscopes Remote Control and Automation Manual
*OPC
Description
The *OPC (Operation Complete) command sets the OPC bit (bit 0) to "true" in the standard Event Status
Register (ESR).
The *OPC? query always responds with the ASCII character 1 because the oscilloscope only responds to
the query when the previous commands are entirely executed. Since *OPC? executes only when
processing is complete, it is recommended for synchronization purposes. See Timing and
Synchronization.
Command Syntax
*OPC
Query Syntax
*OPC?
Response Format
1
Related Commands
*WAI
